| Analogue Ports Qty: | 24 |
|---|---|
| Authentication Method: | RADIUS, TACACS+ |
| Compliant Standards: | IEEE 802.3, ANSI T1.101, ITU-T G.823, ITU-T G.824 |
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 3548 Class A, VCCI V-3, EN 61000, TIA/EIA/IS-968, CNS 13438, EN 300 386, CAN/CS |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Depth: | 34.29 cm |
| Device Type: | VoIP phone adapter |
| Expansion Slots: | 1 (total) / 1 (free) x EHWIC ¦ 1 (total) / 0 (free) x PVDM |
| Features: | Wall mountable |
| Flash Memory: | 256 MB |
| Form Factor: | Rack-mountable |
| Height: | 4.44 cm |
| Height (Rack Units): | 1U |
| Humidity Range Operating: | 10 - 85% |
| IP Telephony Features: | Caller ID, call waiting, automatic fax/modem detection and pass-through, call hold, call transfer |
| Included Accessories: | 64-channel voice DSP module |
| Interfaces: | 2 x 1000Base-T - RJ-45 ¦ 1 x auxiliary - RJ-45 ¦ 1 x console - RJ-45 ¦ 1 x mini-USB ¦ 1 x USB 2.0 - Type A ¦ 24 x FXS - RJ-21 |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | DHCP, DNS |
| Power Consumption Operational: | 135 Watt |
| Power Device: | Internal power supply |
| RAM: | 1 GB SDRAM |
| Remote Management Protocol: | Telnet, SNMP 3, HTTP, TFTP, CLI |
| Routing Protocol: | HSRP |
| Software Included: | Cisco IOS IP Base, Cisco IOS Unified Communications |
| Supported Flash Memory Cards: | CompactFlash Card |
| Telephony Interfaces: | 24 phone (FXS) |
| Version: | original |
| VoIP Protocols: | MGCP, SCCP, SIP, H.323 v4, RTP, SRTP |
| Voice Codecs: | G.711, G.729a, T.38 |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 6.91 kg |
| Width: | 44.45 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Gateways International.pdf |
| Safety instructions: | Safety instructions Gateways International.pdf |
