Aruba JW799A
Aruba AP-334 802.11n/ac 4x4:4 MU-MIMO Dual Radio Antenna Connectors 2.5+1 GbE AP
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Aruba AP-334 802.11n/ac 4x4:4 MU-MIMO Dual Radio Antenna Connectors 2.5+1 GbE AP
| Compliant Standards: | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac |
|---|---|
| Compliant Standards: | EN 60950, IEC 60950, UL 60950, CB, UL 2043, FCC, EN 60601-1-2, cTUVus, EN 300 328, EN 301 489, EN 60601-1-1, LVD 72/23/EEC, R&TTE Directive 1999/5/EC, EN 301 893 |
| Connectivity Technology: | Wireless |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Data Transfer Rate: | 1733 Mbps |
| Depth: | 22.4 cm |
| Device Type: | Radio access point |
| Features: | Auto-uplink (auto MDI/MDI-X), DFS support, reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Energy Efficient Ethernet, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced |
| Form Factor: | In-ceiling |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Height: | 5.2 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Important product information: | Controller-based. Requires additional controller for management. |
| Interfaces: | 1 x 1000Base-T - RJ-45 ¦ 1 x 2500Base-T - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x console - RJ-45 ¦ 4 x aerial - RP-SMA |
| Line Coding Format: | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM |
| MTBF: | 531,662 hours |
| Manufacturer: | Aruba HPE |
| Max Operating Temperature: | 50 °C |
| Min Operating Temperature: | 0 °C |
| Power Consumption Operational: | 25 Watt |
| Power Over Ethernet (PoE) Supported: | PoE |
| Spread Spectrum Method: | OFDM, DSSS |
| Status Indicators: | System, status |
| Version: | original |
| Voltage Required: | DC 48 V |
| Weight: | 1.15 kg |
| Width: | 22.5 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| Warnings: | Warnings Accesspoints International.pdf |
| Safety instructions: | Safety instructions Accesspoints International.pdf |
Important product information
Controller-based. Requires additional controller for management.
