| Cables Included: | Serial cable - external - 1.83 m ¦ USB cable - external - 1.83 m |
|---|---|
| Colour: | Black |
| Compliant Standards: | NOM, cULus |
| Depth: | 41.1 cm |
| Device Type: | UPS - external |
| Efficiency: | 93% |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Advance Battery Management (ABM), LCD display, hot-swappable batteries, 3-stage charging, double conversion, Sealed |
| Frequency Required: | 40 - 70 Hz |
| Height: | 34.5 cm |
| Humidity Range Operating: | 0 - 96% (non-condensing) |
| Input Connectors: | Power IEC 60320 C14, power NEMA L6-20P |
| Input Voltage: | AC 200/208/220/230/240 V |
| Input Voltage Range: | AC 190 - 276 V |
| Input Voltage Range (Adjustable): | AC 120 - 276 V |
| Interfaces: | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ EPO (emergency power off) - mini terminal block |
| Manufacturer: | Eaton |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Output Voltage: | AC 200/208/220/230/240 V |
| Output Waveform: | Sinewave |
| Power Capacity: | 1800 Watt / 2000 VA |
| Power Output Connectors Details: | 8 x power IEC 60320 C13 |
| Quantity: | 8 |
| Remote Management Interface: | RS-232, USB |
| Software Included: | Intelligent Power Manager (up to 10 nodes) |
| Sound Emission: | 50 dBA |
| Surge Suppression: | Yes |
| Technology: | Lead Acid |
| UPS Technology: | On-line |
| Version: | original |
| Weight: | 35 kg |
| Width: | 21.3 cm |
| GPSR - economic actor: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
|---|---|
| GPSR - product manufacturer: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
| GPSR - EU responsible person: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
| Warnings: | Warnings Adapter PCI International.pdf |
| Safety instructions: | Safety instructions Adapter PCI International.pdf |
| Cables Included: | Serial cable - external - 1.83 m ¦ USB cable - external - 1.83 m |
|---|---|
| Colour: | Black |
| Compliant Standards: | NOM, cULus |
| Depth: | 41.1 cm |
| Device Type: | UPS - external |
| Efficiency: | 93% |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Advance Battery Management (ABM), LCD display, hot-swappable batteries, 3-stage charging, double conversion, Sealed |
| Frequency Required: | 40 - 70 Hz |
| Height: | 34.5 cm |
| Humidity Range Operating: | 0 - 96% (non-condensing) |
| Input Connectors: | Power IEC 60320 C14, power NEMA L6-20P |
| Input Voltage: | AC 200/208/220/230/240 V |
| Input Voltage Range: | AC 190 - 276 V |
| Input Voltage Range (Adjustable): | AC 120 - 276 V |
| Interfaces: | 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ EPO (emergency power off) - mini terminal block |
| Manufacturer: | Eaton |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Output Voltage: | AC 200/208/220/230/240 V |
| Output Waveform: | Sinewave |
| Power Capacity: | 1800 Watt / 2000 VA |
| Power Output Connectors Details: | 8 x power IEC 60320 C13 |
| Quantity: | 8 |
| Remote Management Interface: | RS-232, USB |
| Software Included: | Intelligent Power Manager (up to 10 nodes) |
| Sound Emission: | 50 dBA |
| Surge Suppression: | Yes |
| Technology: | Lead Acid |
| UPS Technology: | On-line |
| Version: | original |
| Weight: | 35 kg |
| Width: | 21.3 cm |
| GPSR - economic actor: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
|---|---|
| GPSR - product manufacturer: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
| GPSR - EU responsible person: | Eaton, Deutschland, Hein-Moeller-Str. 7-11, Bonn, 53115, infogermany@eaton.com |
