Cisco SM-X-1T3/E3
One port T3/E3 Service Module
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
One port T3/E3 Service Module
| Compliant Standards: | TUV GS, EN 60950, EN 61000-3-2, IEC950, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 3260, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, AS/NZ 3548 Class A, ICES-003 Class A, EN 61000-4-5, UL 1950 Third Edition, EN 61000-6-2, EN 61000-4-11, FC |
|---|---|
| Compliant Standards: | ANSI T1.107, G.703, ITU-T G.823 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | HDLC, Frame Relay, PPP |
| Data Transfer Rate: | 44.736 Mbps |
| Depth: | 18.3 cm |
| Designed For: | P/N: C1-CISCO4331/K9, C1-CISCO4351/K9, C1-CISCO4451/K9, ISR4331/K9, ISR4331-AX/K9, ISR4331-AXV/K9, ISR4331-DC/K9, ISR4331-DNA, ISR4331-PM20, ISR4331-SEC/K9, ISR4331-V/K9, ISR4331-VSEC/K9, ISR4351/K9, ISR4351-AX/K9, ISR4351-AXV/K9, ISR4351-DNA, ISR4351-PM2 |
| Device Type: | Expansion module |
| Features: | NAT support, Intrusion Detection System (IDS), Quality of Service (QoS), NetFlow |
| Form Factor: | Plug-in module |
| Height: | 3.9 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 1 x T3/E3 - BNC - x 2 |
| Line Coding Format: | HDB3, B3ZS |
| Line Rate: | T-3/E-3 |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | IPSec |
| Status Indicators: | Status, alarm |
| Version: | original |
| Width: | 18 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Controller Cards International.pdf |
| Safety instructions: | Safety instructions Controller Cards International.pdf |
One port T3/E3 Service Module
| Compliant Standards: | TUV GS, EN 60950, EN 61000-3-2, IEC950, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 3260, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, AS/NZ 3548 Class A, ICES-003 Class A, EN 61000-4-5, UL 1950 Third Edition, EN 61000-6-2, EN 61000-4-11, FC |
|---|---|
| Compliant Standards: | ANSI T1.107, G.703, ITU-T G.823 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | HDLC, Frame Relay, PPP |
| Data Transfer Rate: | 44.736 Mbps |
| Depth: | 18.3 cm |
| Designed For: | P/N: C1-CISCO4331/K9, C1-CISCO4351/K9, C1-CISCO4451/K9, ISR4331/K9, ISR4331-AX/K9, ISR4331-AXV/K9, ISR4331-DC/K9, ISR4331-DNA, ISR4331-PM20, ISR4331-SEC/K9, ISR4331-V/K9, ISR4331-VSEC/K9, ISR4351/K9, ISR4351-AX/K9, ISR4351-AXV/K9, ISR4351-DNA, ISR4351-PM2 |
| Device Type: | Expansion module |
| Features: | NAT support, Intrusion Detection System (IDS), Quality of Service (QoS), NetFlow |
| Form Factor: | Plug-in module |
| Height: | 3.9 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 1 x T3/E3 - BNC - x 2 |
| Line Coding Format: | HDB3, B3ZS |
| Line Rate: | T-3/E-3 |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | IPSec |
| Status Indicators: | Status, alarm |
| Version: | original |
| Width: | 18 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
