Allied AT-MC101XL
100TX (RJ-45) to 100FX (ST) Fast Ethernet media converter
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
100TX (RJ-45) to 100FX (ST) Fast Ethernet media converter
| Cabling Type: | 100Base-FX, 100Base-TX |
|---|---|
| Compliant Standards: | IEEE 802.3u, IEEE 802.1Q |
| Compliant Standards: | FCC Class B certified, CSA, UL, TUV, cUL, RoHS |
| Connectivity Technology: | Wired |
| Data Link Protocol: | 10Mb LAN |
| Data Transfer Rate: | 100 Mbps |
| Depth: | 9.5 cm |
| Device Type: | Fibre media converter |
| Features: | Auto-negotiation, MissingLink, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, fanless |
| Form Factor: | External |
| Height: | 2.5 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 1 x Ethernet 100Base-TX - RJ-45 female ¦ 1 x Ethernet 100Base-FX - ST multi-mode female x 2 |
| Manufacturer: | Allied |
| Max Operating Temperature: | 40 °C |
| Max Transfer Distance: | 2 km |
| Min Operating Temperature: | 0 °C |
| Optical Wave Length: | 1310 nm |
| Power Consumption Operational: | 6 Watt |
| Power Device: | External power adapter |
| Rack Mounting Kit: | Optional |
| Status Indicators: | Port duplex mode, power, link OK, link/activity, MissingLink |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 294 g |
| Width: | 10.5 cm |
| GPSR - economic actor: | Allied Telesis, Deutschland, Karl-Hammerschmidt-Straße 34, Aschheim-Dornach, 85609, imprint@alliedtelesis.com |
|---|---|
| GPSR - product manufacturer: | Allied Telesis, Deutschland, Karl-Hammerschmidt-Straße 34, Aschheim-Dornach, 85609, imprint@alliedtelesis.com |
| GPSR - EU responsible person: | Allied Telesis, Deutschland, Karl-Hammerschmidt-Straße 34, Aschheim-Dornach, 85609, imprint@alliedtelesis.com |
| EU Data-Act-Url: | https://www.alliedtelesis.com/de/de/documents/business-partner-contact-data-privacy-notice |
| Warnings: | Warnings Modules International.pdf |
| Safety instructions: | Safety instructions Modules International.pdf |
