Optical transceivers: Flexible fiber optic connections for professional networks
Optical transceivers are essential components for modern corporate networks—they enable data transmission via fiber optics at high speeds and over long distances. Whether single-mode transceivers for long distances or multimode transceivers for shorter distances: the right choice ensures scalability, efficiency, and investment security in your IT infrastructure.
Do you have questions about our products in this category?
Our team will advise you extensively on your questions:
+49 (0) 39203 96 96 100
SFP, Gigabit Ethernet CWDM Optics, 1590nm for 80 km Transmission on SMF, compatible
CIENA - SFP+ transceiver module - 10GbE - 10GBase-DWDM - LC single-mode - up to 40 km - channel: 50 - 1537.40 nm, compatible
SFP, 1G, Copper 100m, Standard Temperature (0 through 70 DegC), RJ-45 connector, compatible
QSFP+ 40GBase-LR4 40 Gigabit Optics for up to 1km transmission over parallel SMF
Small Form Factor Pluggable 1000Base-T Gigabit Ethernet Module (uses Cat 5 cable) compatible
1000Base-SX Gigabit Ethernet optical transceiver (SFP MSA). Supports multimode fiber over 850nm wavelength (nominal) with an LC connector. Typical reach of 300m on 62.5/125 µm MMF or 550m on 50/125 µm MMF.
1 Gb, 1000Base-LX/LH, IEEE 802.3 SM, 1550 nm Long Wave Length, 80 KM, LC SFP, compatible
HPE B-series 64Gb SFP56 Extended Long Wave 25km 1-pack Secure Transceiver - compatible
1 Gb, 1000Base-LX, IEEE 802.3 SM, 1310 nm Long Wave Length, 10 Km, LC SFP, compatible
What is an optical transceiver?
An optical transceiver converts electrical signals into light signals and transmits them via fiber optic cables. The transceiver modules are interchangeable and are typically used in network components such as switches, routers, or firewalls.
Differences exist depending on:
- Transmission rate (e.g., 1G, 10G, 25G, 100G, 400G)
- Form factor (SFP, SFP+, QSFP, QSFP28, QSFP-DD, etc.)
- Range (multimode up to approx. 550 m, singlemode up to 40 km+)
Form factors at a glance: SFP, QSFP & Co.
Different designs are used depending on network requirements:
SFP & SFP+
- SFP (1G SFP): Standard for Gigabit connections
- SFP+ (10G SFP): For 10 Gigabit Ethernet – compact, energy-efficient, and widely used
- SFP28 (25G SFP28): For modern data centers and backbone connections
- SFP56: Supports 50 Gbit/s – for high-throughput applications
- SFP-DD: Double density for two signals in the smallest of spaces
QSFP formats for higher bandwidths
- QSFP (40G QSFP): 4x10G – established in core and aggregation layers
- QSFP28 (100G QSFP28): Standard module for 100G backbone connections
- QSFP-DD (200G/400G QSFP-DD): Eight-channel high-performance transceivers – for hyperscale networks
- QSFP56: Supports 200 Gbit/s via 4x50G – future-proof solution for data centers
Singlemode vs. Multimode Transceivers: When to use which?
Single-mode transceivers
- Ideal for long distances (up to 40–80 km)
- Low attenuation and long range
- Use in wide area networks or between buildings
Multimode transceiver
- Cost-effective for shorter distances (up to approx. 500 m)
- Lower installation costs thanks to inexpensive OM3/OM4 fibers
- Frequently used in server rooms and building networks
Tip: When selecting a transceiver, make sure it is compatible with your switch or router. Most manufacturers provide compatibility lists or recommendations.
Frequently asked questions about optical transceivers
What is the difference between SFP and SFP+?
Both formats are identical in design, but differ in speed: SFP supports 1 Gbit/s, SFP+ up to 10 Gbit/s.
Are optical transceivers compatible across manufacturers?
Many devices only accept transceivers with the correct code. it-market therefore offers compatible alternatives to OEM modules that are fully functional and tested – e.g., 100G QSFP28 for Cisco, HPE, or Dell.
What does “hot-swappable” mean?
Transceivers can be replaced during operation – without restarting the system. This minimizes downtime during maintenance or expansion.
Optical transceivers: new, used, and refurbished at it-market
At it-market, you will find a wide selection of optical transceivers – in all form factors and speeds. Whether 1G SFP, 10G SFP+, 25G SFP28, 100G QSFP28, or 400G QSFP-DD: we carry tested new and used goods as well as refurbished modules.
Benefit from:
- 3-year warranty for companies
- Up to €2,500 buyer protection
- Short delivery times
Do you have any questions? Our sales team will be happy to answer any questions you may have about IT hardware and IT remarketing.
