Cisco CISCO886VA-J-K9
Cisco 886VA Annex J router with VDSL2/ADSL2 over ISDN
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Cisco 886VA Annex J router with VDSL2/ADSL2 over ISDN
| Authentication Method: | RADIUS, TACACS+ |
|---|---|
| Capacity: | IPSec VPN tunnels: 20 |
| Compliant Standards: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, VCCI, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 50082-2, FCC CFR47 Part 15, EN 300 386 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet |
| Depth: | 24.9 cm |
| Device Type: | Router - 4-port switch (integrated) |
| Digital Signaling Protocol: | ADSL2+ over ISDN, VDSL2 over ISDN |
| Enclosure Type: | Desktop |
| Encryption Algorithm: | DES, Triple DES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES |
| Expansion Slots: | 1 (total) / 1 (free) x SO-DIMM 200-pin |
| Features: | Firewall protection, DHCP support, NAT support, VLAN support, auto-uplink (auto MDI/MDI-X), Stateful Packet Inspection (SPI), dynamic DNS server, MAC address filtering, Broadcast Storm Control, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing |
| Flash Memory: | 128 MB |
| Framing Format: | ANSI T1.413 |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Interfaces: | LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ WAN: 1 x ADSL2+ over ISDN ¦ USB: 1 x 4 pin USB Type A ¦ WAN: 1 x BRI ST |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | L2TP, IPSec, PPPoE, PPPoA, DHCP, DNS |
| OS Provided: | Cisco IOS Advanced Security |
| Power Device: | External power adapter - 60 Watt |
| Protocols & Specifications: | ITU G.992.1 (G.DMT), ITU G.994.1 (G.hs), ITU G.992.3 (G.DMT.bis), ITU G.992.5 |
| RAM: | 256 MB (installed) / 768 MB (max) - DDR2 SDRAM - SO-DIMM 200-pin |
| Remote Management Protocol: | Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Routing Protocol: | RIP-1, RIP-2, HSRP, VRRP, GRE, policy-based routing (PBR) |
| Status Indicators: | Port status, power |
| Type: | ISDN / DSL modem combo |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 2.5 kg |
| Width: | 32.5 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| Warnings: | Warnings Routers International.pdf |
| Safety instructions: | Safety instructions Routers International.pdf |
Cisco 886VA Annex J router with VDSL2/ADSL2 over ISDN
| Authentication Method: | RADIUS, TACACS+ |
|---|---|
| Capacity: | IPSec VPN tunnels: 20 |
| Compliant Standards: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, VCCI, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 50082-2, FCC CFR47 Part 15, EN 300 386 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet |
| Depth: | 24.9 cm |
| Device Type: | Router - 4-port switch (integrated) |
| Digital Signaling Protocol: | ADSL2+ over ISDN, VDSL2 over ISDN |
| Enclosure Type: | Desktop |
| Encryption Algorithm: | DES, Triple DES, SSL, PKI, 128-bit AES, 192-bit AES, 256-bit AES |
| Expansion Slots: | 1 (total) / 1 (free) x SO-DIMM 200-pin |
| Features: | Firewall protection, DHCP support, NAT support, VLAN support, auto-uplink (auto MDI/MDI-X), Stateful Packet Inspection (SPI), dynamic DNS server, MAC address filtering, Broadcast Storm Control, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing |
| Flash Memory: | 128 MB |
| Framing Format: | ANSI T1.413 |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Interfaces: | LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ WAN: 1 x ADSL2+ over ISDN ¦ USB: 1 x 4 pin USB Type A ¦ WAN: 1 x BRI ST |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | L2TP, IPSec, PPPoE, PPPoA, DHCP, DNS |
| OS Provided: | Cisco IOS Advanced Security |
| Power Device: | External power adapter - 60 Watt |
| Protocols & Specifications: | ITU G.992.1 (G.DMT), ITU G.994.1 (G.hs), ITU G.992.3 (G.DMT.bis), ITU G.992.5 |
| RAM: | 256 MB (installed) / 768 MB (max) - DDR2 SDRAM - SO-DIMM 200-pin |
| Remote Management Protocol: | Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
| Routing Protocol: | RIP-1, RIP-2, HSRP, VRRP, GRE, policy-based routing (PBR) |
| Status Indicators: | Port status, power |
| Type: | ISDN / DSL modem combo |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 2.5 kg |
| Width: | 32.5 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
