Cisco SRP521W-K9-G5
SRP521, FE WAN, 802.11n ETSI, 2FXS/1FXO, EU/UK power
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
SRP521, FE WAN, 802.11n ETSI, 2FXS/1FXO, EU/UK power
| Antenna: | External integrated |
|---|---|
| Antenna Qty: | 1 |
| Authentication Method: | RADIUS, Radio Service Set ID (SSID) |
| Cables Included: | 1 x network cable ¦ 1 x phone cable |
| Capacity: | IPSecVPN tunnels: 5 |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n, ETSI, CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, AS/NZS 60950-1, RSS-210, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC |
| Connectivity Technology: | Wireless, wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Device Type: | Wireless router - 4-port switch (integrated) |
| Enclosure Type: | Desktop |
| Encryption Algorithm: | Triple DES, 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA2 |
| Features: | NAT support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, traffic shaping, Stateful Packet Inspection (SPI), DoS attack prevention, VPN passthrough, URL filtering, Low-latency queuing (LLQ), Weighted Fair Queuing (WFQ), Wi-Fi M |
| Flash Memory: | 32 MB |
| Gain Level: | 2.2 dBi |
| Humidity Range Operating: | 5 - 95% |
| IP Telephony Features: | Echo cancellation, comfort noise generation (CNG), voice activity detection (VAD), Caller ID, call waiting, call hold, call transfer, silence suppression, DTMF generation/detection |
| Interfaces: | LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX - RJ-45 ¦ Phone line: 1 x FXO - RJ-11 ¦ Phone line: 2 x FXS - RJ-11 ¦ USB 2.0: 1 x 4 pin USB Type A |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, L2TP, PPPoE |
| Power Device: | External power adapter |
| RAM: | 64 MB |
| Remote Management Protocol: | SNMP 2, HTTP, HTTPS |
| Routing Protocol: | RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3, GRE |
| Software Included: | Drivers & Utilities |
| Status Indicators: | Port status, power |
| Telephony Interfaces: | 2 phone (FXS), 1 line (FXO) |
| Version: | original |
| VoIP Functionality: | VoIP phone adapter |
| VoIP Protocols: | SIP v2 |
| Voice Codecs: | G.711, G.723.1, G.726 |
| Voltage Required: | AC 120/230 V |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Routers International.pdf |
| Safety instructions: | Safety instructions Routers International.pdf |
SRP521, FE WAN, 802.11n ETSI, 2FXS/1FXO, EU/UK power
| Antenna: | External integrated |
|---|---|
| Antenna Qty: | 1 |
| Authentication Method: | RADIUS, Radio Service Set ID (SSID) |
| Cables Included: | 1 x network cable ¦ 1 x phone cable |
| Capacity: | IPSecVPN tunnels: 5 |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n, ETSI, CISPR 24, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, AS/NZS 60950-1, RSS-210, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC |
| Connectivity Technology: | Wireless, wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Device Type: | Wireless router - 4-port switch (integrated) |
| Enclosure Type: | Desktop |
| Encryption Algorithm: | Triple DES, 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA2 |
| Features: | NAT support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, traffic shaping, Stateful Packet Inspection (SPI), DoS attack prevention, VPN passthrough, URL filtering, Low-latency queuing (LLQ), Weighted Fair Queuing (WFQ), Wi-Fi M |
| Flash Memory: | 32 MB |
| Gain Level: | 2.2 dBi |
| Humidity Range Operating: | 5 - 95% |
| IP Telephony Features: | Echo cancellation, comfort noise generation (CNG), voice activity detection (VAD), Caller ID, call waiting, call hold, call transfer, silence suppression, DTMF generation/detection |
| Interfaces: | LAN: 4 x 10Base-T/100Base-TX - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX - RJ-45 ¦ Phone line: 1 x FXO - RJ-11 ¦ Phone line: 2 x FXS - RJ-11 ¦ USB 2.0: 1 x 4 pin USB Type A |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, L2TP, PPPoE |
| Power Device: | External power adapter |
| RAM: | 64 MB |
| Remote Management Protocol: | SNMP 2, HTTP, HTTPS |
| Routing Protocol: | RIP-1, RIP-2, IGMPv2, IGMP, static IP routing, IGMPv3, GRE |
| Software Included: | Drivers & Utilities |
| Status Indicators: | Port status, power |
| Telephony Interfaces: | 2 phone (FXS), 1 line (FXO) |
| Version: | original |
| VoIP Functionality: | VoIP phone adapter |
| VoIP Protocols: | SIP v2 |
| Voice Codecs: | G.711, G.723.1, G.726 |
| Voltage Required: | AC 120/230 V |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
