Fortinet FG-1100E-BDL-809-12
FortiGate-1100E Hardware plus 1 Year Hardware plus FortiCare Premium and FortiGuard Enterprise Protection
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
FortiGate-1100E Hardware plus 1 Year Hardware plus FortiCare Premium and FortiGuard Enterprise Protection
| Airflow Direction: | Front to back airflow |
|---|---|
| Bundled Services: | 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection |
| Capacity: | Concurrent TCP sessions: 8000000 ¦ New TCP sessions per second: 500000 ¦ Firewall policies: 100000 ¦ Gateway to gateway IPSec VPN Tunnels: 20000 ¦ Client to gateway IPSec VPN tunnels: 100000 ¦ Concurrent SSL VPN users: 10000 ¦ SSL inspection CPS: 6500 ¦ S |
| Compliant Standards: | UL, VCCI, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC, ICES, RCM, USGv6, ICSA SSL-VPN, ICSA IPS |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 25 Gigabit Ethernet |
| Depth: | 44.74 cm |
| Device Type: | Security appliance |
| Encryption Algorithm: | SSL, 256-bit AES, 256-bit SHA, TLS 1.3 |
| Features: | VPN support, CAPWAP support, SSL inspection, IP tunnel acceleration |
| Form Factor: | Rack-mountable |
| Height: | 8.89 cm |
| Height (Rack Units): | 2U |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Included Accessories: | 2 SX SFP transceivers |
| Installed Qty: | 2 |
| Interfaces: | 2 x USB 3.0 - Type A ¦ 1 x console - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x 1000Base-T (HA) - RJ-45 ¦ 16 x 1000Base-T - RJ-45 ¦ 8 x 1000Base-X - SFP ¦ 4 x 1000Base-X/10GBase-X - SFP/SFP+ ¦ 4 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SF |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, IPSec, SCTP, HTTP, HTTPs, IPv4, IPv6 |
| OS Provided: | FortiOS |
| Performance: | IPS throughput (enterprise traffic mix): 12.5 Gbps ¦ NGFW throughput (enterprise traffic mix): 9.8 Gbps ¦ Threat protection throughput (enterprise traffic mix): 7.11 Gbps ¦ Firewall throughput (1518-byte UDP): 80 Gbps ¦ Firewall throughput (512-byte UDP): |
| Power Consumption Operational: | 217 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Yes |
| Processors Installed: | Fortinet FortiASIC CP9/NP6 |
| Remote Management Protocol: | HTTP, HTTPS |
| Status Indicators: | Power, status, alarm, HA |
| Version: | original |
| Voltage Required: | AC 100-240 V (50/60 Hz) |
| Weight: | 11.3 kg |
| Width: | 44.3 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
| Warnings: | Warnings Firewalls International.pdf |
| Safety instructions: | Safety instructions Firewalls International.pdf |
FortiGate-1100E Hardware plus 1 Year Hardware plus FortiCare Premium and FortiGuard Enterprise Protection
| Airflow Direction: | Front to back airflow |
|---|---|
| Bundled Services: | 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection |
| Capacity: | Concurrent TCP sessions: 8000000 ¦ New TCP sessions per second: 500000 ¦ Firewall policies: 100000 ¦ Gateway to gateway IPSec VPN Tunnels: 20000 ¦ Client to gateway IPSec VPN tunnels: 100000 ¦ Concurrent SSL VPN users: 10000 ¦ SSL inspection CPS: 6500 ¦ S |
| Compliant Standards: | UL, VCCI, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC, ICES, RCM, USGv6, ICSA SSL-VPN, ICSA IPS |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 25 Gigabit Ethernet |
| Depth: | 44.74 cm |
| Device Type: | Security appliance |
| Encryption Algorithm: | SSL, 256-bit AES, 256-bit SHA, TLS 1.3 |
| Features: | VPN support, CAPWAP support, SSL inspection, IP tunnel acceleration |
| Form Factor: | Rack-mountable |
| Height: | 8.89 cm |
| Height (Rack Units): | 2U |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Included Accessories: | 2 SX SFP transceivers |
| Installed Qty: | 2 |
| Interfaces: | 2 x USB 3.0 - Type A ¦ 1 x console - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x 1000Base-T (HA) - RJ-45 ¦ 16 x 1000Base-T - RJ-45 ¦ 8 x 1000Base-X - SFP ¦ 4 x 1000Base-X/10GBase-X - SFP/SFP+ ¦ 4 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SF |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, IPSec, SCTP, HTTP, HTTPs, IPv4, IPv6 |
| OS Provided: | FortiOS |
| Performance: | IPS throughput (enterprise traffic mix): 12.5 Gbps ¦ NGFW throughput (enterprise traffic mix): 9.8 Gbps ¦ Threat protection throughput (enterprise traffic mix): 7.11 Gbps ¦ Firewall throughput (1518-byte UDP): 80 Gbps ¦ Firewall throughput (512-byte UDP): |
| Power Consumption Operational: | 217 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Yes |
| Processors Installed: | Fortinet FortiASIC CP9/NP6 |
| Remote Management Protocol: | HTTP, HTTPS |
| Status Indicators: | Power, status, alarm, HA |
| Version: | original |
| Voltage Required: | AC 100-240 V (50/60 Hz) |
| Weight: | 11.3 kg |
| Width: | 44.3 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
