Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| Capacity: | Client to gatewayIPSecVPN tunnels: 10000 ¦ Gateway to gatewayIPSecVPN Tunnels: 2000 ¦ Concurrent sessions: 6000000 ¦ New sessions per second: 200000 ¦ Firewall policies: 10000 ¦ Concurrent SSL VPN users: 500 ¦ Virtual domains: 10 ¦ Number of FortiAP d |
|---|---|
| Compliant Standards: | UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 A |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Depth: | 32.2 cm |
| Device Type: | Security appliance |
| Encryption Algorithm: | SSL |
| Features: | Firewall protection, VPN support, traffic shaping, manageable, IPv6 support, antivirus analysis, Intrusion Prevention System (IPS), IPv4 support, checksum offload support |
| Form Factor: | Rack-mountable |
| Hard Drive: | SSD 120 GB x 1 |
| Height: | 4.4 cm |
| Height (Rack Units): | 1U |
| Humidity Range Operating: | 20 - 90% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 2 x USB - Type A ¦ 1 x USB - Type B ¦ 1 x console - RJ-45 ¦ 4 x 1000Base-T - RJ-45 ¦ 4 x Ethernet 1000 - SFP (mini-GBIC) ¦ 2 x management - RJ-45 |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 1 |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, IPSec |
| OS Provided: | FortiOS 5 |
| Performance: | Firewall throughput (1518-byte packet size): 8 Gbps ¦ Firewall throughput (512-byte packet size): 8 Gbps ¦ Firewall throughput (64-byte packet size): 8 Gbps ¦ IPS throughput: 2.8 Gbps ¦ VPN throughput (512-bitIPSec): 7 Gbps ¦ Proxy-based antivirus throug |
| Power Consumption Operational: | 194 Watt |
| Power Device: | Internal power supply |
| Power Redundancy: | Yes |
| Processors Installed: | 1 x Fortinet FortiASIC CP8 |
| Version: | original |
| Voltage Required: | AC 120/230 V |
| Weight: | 4.8 kg |
| Width: | 43.2 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| EU Data-Act-Url: | https://www.fortinet.com/de/corporate/about-us/gdpr |
| Warnings: | Warnings Firewalls International.pdf |
| Safety instructions: | Safety instructions Firewalls International.pdf |
| Capacity: | Client to gatewayIPSecVPN tunnels: 10000 ¦ Gateway to gatewayIPSecVPN Tunnels: 2000 ¦ Concurrent sessions: 6000000 ¦ New sessions per second: 200000 ¦ Firewall policies: 10000 ¦ Concurrent SSL VPN users: 500 ¦ Virtual domains: 10 ¦ Number of FortiAP d |
|---|---|
| Compliant Standards: | UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 A |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Depth: | 32.2 cm |
| Device Type: | Security appliance |
| Encryption Algorithm: | SSL |
| Features: | Firewall protection, VPN support, traffic shaping, manageable, IPv6 support, antivirus analysis, Intrusion Prevention System (IPS), IPv4 support, checksum offload support |
| Form Factor: | Rack-mountable |
| Hard Drive: | SSD 120 GB x 1 |
| Height: | 4.4 cm |
| Height (Rack Units): | 1U |
| Humidity Range Operating: | 20 - 90% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 2 x USB - Type A ¦ 1 x USB - Type B ¦ 1 x console - RJ-45 ¦ 4 x 1000Base-T - RJ-45 ¦ 4 x Ethernet 1000 - SFP (mini-GBIC) ¦ 2 x management - RJ-45 |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 1 |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | TCP/IP, UDP/IP, IPSec |
| OS Provided: | FortiOS 5 |
| Performance: | Firewall throughput (1518-byte packet size): 8 Gbps ¦ Firewall throughput (512-byte packet size): 8 Gbps ¦ Firewall throughput (64-byte packet size): 8 Gbps ¦ IPS throughput: 2.8 Gbps ¦ VPN throughput (512-bitIPSec): 7 Gbps ¦ Proxy-based antivirus throug |
| Power Consumption Operational: | 194 Watt |
| Power Device: | Internal power supply |
| Power Redundancy: | Yes |
| Processors Installed: | 1 x Fortinet FortiASIC CP8 |
| Version: | original |
| Voltage Required: | AC 120/230 V |
| Weight: | 4.8 kg |
| Width: | 43.2 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| EU Data-Act-Url: | https://www.fortinet.com/de/corporate/about-us/gdpr |
