APC SRT3000RMXLT
APC Smart-UPS SRT 3000VA RM 208V
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
APC Smart-UPS SRT 3000VA RM 208V
| Compliant Standards: | cUL, UL 1778, RoHS, FCC Part 15 A, REACH, IP20 |
|---|---|
| Depth: | 63.5 cm |
| Designed For: | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, AP5017, AP5602, AP5606, AP5607, AP5 |
| Device Type: | UPS - rack-mountable |
| ENERGY STAR: | Yes |
| Efficiency: | 92.7% at 100% Load |
| Enclosure Colour: | Black |
| Expansion Slots: | 1 (total) / 1 (free) x SmartSlot |
| Features: | Audible alarm, LCD display, internal bypass, Eco-Mode |
| Frequency Provided: | 50/60 Hz |
| Frequency Required: | 40 - 70 Hz |
| Height: | 8.5 cm |
| Height (Rack Units): | 2U |
| Humidity Range Operating: | 0 - 95% (non-condensing) |
| Included Accessories: | Rack mounting rails |
| Input Connectors: | 1 x power NEMA L6-20 |
| Input Voltage: | AC 208/240 V |
| Input Voltage Range: | AC 160 - 275 V |
| Input Voltage Range (Adjustable): | AC 100 - 275 V |
| Interfaces: | 1 x serial - RJ-45 ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB) - 4 pin USB Type A |
| Manufacturer: | APC Schneider |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Output Voltage: | AC 208/240 V 50/60 Hz |
| Output Waveform: | Sinewave |
| Power Capacity: | 2700 Watt / 3000 VA |
| Power Output Connectors Details: | 2 x power NEMA L6-20 ¦ 1 x power NEMA L6-30 |
| Rack Mounting Kit: | Included |
| Recharge Time: | 3 hours |
| Remote Management Interface: | RS-232, USB |
| Run Time (Up To): | 3.8 min at full load ¦ 11.4 min at half load |
| Shipping Depth: | 87.1 cm |
| Shipping Height: | 24.6 cm |
| Shipping Weight: | 39.92 kg |
| Shipping Width: | 59.9 cm |
| Software Included: | Drivers & Utilities |
| Sound Emission: | 55 dBA |
| Surge Energy Rating: | 340 Joules |
| Surge Suppression: | Yes |
| Technology: | Lead Acid |
| UPS Technology: | On-line |
| Version: | original |
| Weight: | 31.3 kg |
| Width: | 43.2 cm |
| GPSR - economic actor: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
|---|---|
| GPSR - product manufacturer: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
| GPSR - EU responsible person: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
| Warnings: | Warnings UPS Systems & Power Distribution International.pdf |
| Safety instructions: | Safety instructions UPS Systems & Power Distribution International.pdf |
APC Smart-UPS SRT 3000VA RM 208V
| Compliant Standards: | cUL, UL 1778, RoHS, FCC Part 15 A, REACH, IP20 |
|---|---|
| Depth: | 63.5 cm |
| Designed For: | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, AP5017, AP5602, AP5606, AP5607, AP5 |
| Device Type: | UPS - rack-mountable |
| ENERGY STAR: | Yes |
| Efficiency: | 92.7% at 100% Load |
| Enclosure Colour: | Black |
| Expansion Slots: | 1 (total) / 1 (free) x SmartSlot |
| Features: | Audible alarm, LCD display, internal bypass, Eco-Mode |
| Frequency Provided: | 50/60 Hz |
| Frequency Required: | 40 - 70 Hz |
| Height: | 8.5 cm |
| Height (Rack Units): | 2U |
| Humidity Range Operating: | 0 - 95% (non-condensing) |
| Included Accessories: | Rack mounting rails |
| Input Connectors: | 1 x power NEMA L6-20 |
| Input Voltage: | AC 208/240 V |
| Input Voltage Range: | AC 160 - 275 V |
| Input Voltage Range (Adjustable): | AC 100 - 275 V |
| Interfaces: | 1 x serial - RJ-45 ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB) - 4 pin USB Type A |
| Manufacturer: | APC Schneider |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Output Voltage: | AC 208/240 V 50/60 Hz |
| Output Waveform: | Sinewave |
| Power Capacity: | 2700 Watt / 3000 VA |
| Power Output Connectors Details: | 2 x power NEMA L6-20 ¦ 1 x power NEMA L6-30 |
| Rack Mounting Kit: | Included |
| Recharge Time: | 3 hours |
| Remote Management Interface: | RS-232, USB |
| Run Time (Up To): | 3.8 min at full load ¦ 11.4 min at half load |
| Shipping Depth: | 87.1 cm |
| Shipping Height: | 24.6 cm |
| Shipping Weight: | 39.92 kg |
| Shipping Width: | 59.9 cm |
| Software Included: | Drivers & Utilities |
| Sound Emission: | 55 dBA |
| Surge Energy Rating: | 340 Joules |
| Surge Suppression: | Yes |
| Technology: | Lead Acid |
| UPS Technology: | On-line |
| Version: | original |
| Weight: | 31.3 kg |
| Width: | 43.2 cm |
| GPSR - economic actor: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
|---|---|
| GPSR - product manufacturer: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
| GPSR - EU responsible person: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
