APC SUM3000RMXLI2U
APC Smart-UPS XL Modular 3000VA - UPS - AC 230 V - 2.85 kW - 3000 VA - 2U - black
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
APC Smart-UPS XL Modular 3000VA - UPS - AC 230 V - 2.85 kW - 3000 VA - 2U - black
| Battery Enclosure Type: | Plug-in module |
|---|---|
| Cables Included: | Serial cable ¦ USB cable ¦ Power cable 3 m |
| Compliant Standards: | C-Tick, GOST, EN 61000-3-2, UL 1449, EN55022 Class A |
| Depth: | 68 cm |
| Designed For: | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, AP5017, AP5602, AP5606, AP5607, AP5 |
| Device Type: | UPS - external |
| Enclosure Colour: | Black |
| Expansion Slots: | 1 (total) / 0 (free) x SmartSlot |
| Features: | Audible alarm |
| Frequency Provided: | 50/60 Hz |
| Frequency Required: | 50/60 Hz |
| Height: | 9 cm |
| Height (Rack Units): | 2U |
| Humidity Range Operating: | 0 - 95% |
| Input Connectors: | 1 x power IEC 60320 C20 |
| Input Voltage: | AC 230 V |
| Input Voltage Range: | ± 5% |
| Input Voltage Range (Adjustable): | AC 151 - 302 V |
| Interfaces: | 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB ¦ 1 x LAN - RJ-45 |
| Manufacturer: | APC Schneider |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Output Voltage: | AC 230 V 50/60 Hz |
| Output Waveform: | Sinewave |
| Power Capacity: | 2.85 kW / 3000 VA |
| Power Output Connectors Details: | 7 x power IEC 60320 C13 ¦ 1 x power IEC 60320 C19 |
| Rack Mounting Kit: | Included |
| Run Time (Up To): | 3.5 min at full load |
| Software Included: | Drivers & Utilities |
| Surge Energy Rating: | 490 Joules |
| Surge Suppression: | Yes |
| UPS Technology: | Line interactive |
| Version: | original |
| Weight: | 47 kg |
| Width: | 43 cm |
| GPSR - economic actor: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
|---|---|
| GPSR - product manufacturer: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
| GPSR - EU responsible person: | Schneider Electric GmbH, Deutschland, Gothaer Str. 29, Ratingen, 40880, esupport.emeade @ schneider-electric.com |
| Warnings: | Warnings UPS Systems & Power Distribution International.pdf |
| Safety instructions: | Safety instructions UPS Systems & Power Distribution International.pdf |
