Lenovo 4587A11
Lenovo Storage D1212 LFF Chassis, Dual ESM (US English documentation)
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Lenovo Storage D1212 LFF Chassis, Dual ESM (US English documentation)
| Built-in Devices: | 2 x 3-port environmental service module (ESM) |
|---|---|
| CPU: | No CPU |
| Compliant Standards: | NEBS level 3, CISPR 22 Class A, BSMI CNS 13438 Class A, EN55024, CCC, ICES-003 Class A, RoHS, EN 60950-1, FCC Part 15 A, GB 17625.1, KC, GB 9254 Class A, VCCI Class A, EAC, NMB-3 Class A, GB 4943.1, CNS 14336, NOM-019, EN 55022 Class A, UL/CSA60950-1 |
| Depth: | 63 cm |
| Device Type: | Storage enclosure |
| Enclosure Type: | Rack-mountable - 2U |
| Expansion Bays: | 12 (total) / 12 (free) x hot-swap - 3.5" LFF |
| Height: | 8.8 cm |
| Humidity Range Operating: | 20 - 80% (non-condensing) |
| Included Accessories: | Rack mounting kit |
| Interfaces: | 6 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) ¦ 2 x (management) - RJ-45 |
| Localisation: | US English / Worldwide (excluding China, Japan) |
| Manufacturer: | Lenovo |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 5 °C |
| Power Device: | 2 x internal power supply - hot-plug |
| Power Provided: | 580 Watt |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Supported Devices / Modules Qty: | 12 |
| Supported Drives: | SAS-3 |
| Type: | No HDD |
| Version: | original |
| Voltage Required: | AC 120/230 V - 50/60 Hz |
| Weight: | 16.8 kg |
| Width: | 44.3 cm |
| GPSR - economic actor: | Lenovo, Deutschland, Meitnerstr.9, Stuttgart, 70563, Fragen_DE@lenovo.com |
|---|---|
| GPSR - product manufacturer: | Lenovo, Deutschland, Meitnerstr.9, Stuttgart, 70563, Fragen_DE@lenovo.com |
| GPSR - EU responsible person: | Lenovo, Deutschland, Meitnerstr.9, Stuttgart, 70563, Fragen_DE@lenovo.com |
| EU Data-Act-Url: | https://www.lenovo.com/us/en/privacy/?orgRef=https%253A%252F%252Fnews.lenovo.com%252F |
| Warnings: | Warnings Storage Accessoires International.pdf |
| Safety instructions: | Safety instructions Storage Accessoires International.pdf |
