Broadcom 05-25716-00

Broadcom MegaRAID SAS 9380-8i8e - Storage controller (RAID) - 8 Channel - SATA / SAS 12Gb/s - low profile - RAID 0, 1, 5, 6, 10, 50, JBOD, 60 - PCIe 3.0 x8

Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.

Broadcom MegaRAID SAS 9380-8i8e - Storage controller (RAID) - 8 Channel - SATA / SAS 12Gb/s - low profile - RAID 0, 1, 5, 6, 10, 50, JBOD, 60 - PCIe 3.0 x8
Buffer Size: 2 GB
Channel Qty: 8
Compliant Standards: EN55022, EN55024, ICES-003 Class B, RoHS, WEEE, VCCI V-3, AS/NZS CISPR 22, CNS 13438, FCC CFR47 Part 15 B Class B, IEC/EN/UL 60950
Data Transfer Rate: 12 Gbit/s
Depth: 16.8 cm
Device Type: Storage controller (RAID) - plug-in card - low profile
Features: Load Balancing, DDF compliant Configuration on Disk (COD), Online Capacity Expansion (OCE), Online RAID Level Migration (RLM), SCSI Enclosure Services (SES), CacheVault flash cache protection, automatic disk rebuild, S.M.A.R.T. support, UEFI support, SSD
Height: 6.89 cm
Host Bus: PCIe 3.0 x8
Included Accessories: Low-profile bracket
Interface: SATA / SAS 12Gb/s
Interfaces: 2 x SAS 12Gb/s - 4 x Mini SAS HD (SFF-8643) (internal) ¦ 2 x SAS 12Gb/s - 36 pin 4x Mini SAS HD (SFF-8644) (external)
MTBF: 2,500,000 hours
Manufacturer: Broadcom
Max Operating Temperature: 55 °C
Max Storage Devices Qty: 240
OS Required: FreeBSD, Red Hat Linux, SuSe Linux, Microsoft Windows, Debian Linux, CentOS, Oracle Solaris, VMware ESX, Oracle Linux, Canonical Ubuntu, Linux Fedora
Processor: SAS3316
RAID Level: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60
Software Included: MegaRAID Storage Manager, LSI StorCLI, MegaRAID CacheCade Pro 2.0
Supported Devices: Hard drive, disk array (RAID), solid state drive
Version: original
GPSR - economic actor: Broadcom, Deutschland, Willy Brandt Platz 2 Riem Arcaden, München, 81829, press.relations @ broadcom.com
GPSR - product manufacturer: Broadcom, Deutschland, Willy Brandt Platz 2 Riem Arcaden, München, 81829, press.relations @ broadcom.com
GPSR - EU responsible person: Broadcom, Deutschland, Willy Brandt Platz 2 Riem Arcaden, München, 81829, press.relations @ broadcom.com
Warnings: Warnings Other Storage Products International.pdf
Safety instructions: Safety instructions Other Storage Products International.pdf
Quantity: Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
16 available For special requests or large quantities, please contact us.

Delivery time: ca. 5-10 days The stated delivery times apply to shipping within Germany. Information on deliveries to other countries can be found here.

Product number: 1203345-810866
