Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Fixed 1RU chassis 24 RJ 45 PoE 10/100/1G BaseT 2 10G SFP+ uplink ports 2 SFP(+) as 1G uplinks 10G stacking 370W power budget
| Authentication Method: | RADIUS, TACACS+, Secure Shell v.2 (SSH2), LDAP, Extensible Authentication Protocol (EAP) |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 1024 ¦ IPv4 routes (static): 32 ¦ IPv4 interfaces: 24 ¦ Multicast groups: 1000 |
| Compliant Standards: | C-Tick, EN 61000-3-2, EN55022, EN 61000-3-3, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EMC, EN 61000-4-5, EN 61000-4-11, RoHS, EN 61000-4-8, IEC 60950-1, UL 60950-1 Second Edition, WEEE, ANATEL, EN 60825-1, AS/NZS 3548 Class A, AS/NZS 6, IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.3ak, IEEE 802.1ab (LLDP), I |
| Depth: | 30 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | MD5, PKI, ESP, HMAC |
| Features: | Flow control, DHCP support, auto-negotiation, BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP |
| Flash Memory: | 512 MB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE+ ¦ 2 x 10Gbit LANSFP+ uplink ¦ 2 x Gigabit / 10Gbit LANSFP+ uplink/stacking ¦ 1 x console RJ-45 ¦ 1 x USB Type A management |
| Jumbo Frame Support: | 12KB |
| Localisation: | Europe |
| MAC Address Table Size: | 16K entries |
| MTBF: | 693,000 hours |
| Manufacturer: | Alcatel-Lucent Nokia |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 60 °C |
| Max Units In A Stack: | 4 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -20 °C |
| Performance: | Latency: 4 µs ¦ Switching ASIC capacity: 128 Gbps ¦ Switching capacity (full duplex): 128 Gbps ¦ Frame rate: 95.2 Mpps ¦ Maximum virtual chassis interconnect capacity: 40 Gbps |
| PoE Budget: | 370 W |
| Ports: | 24 x 10/100/1000 (PoE+) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) |
| Power Consumption Operational: | 40.2 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| Processor: | 1 x MIPS: 1 GHz |
| RAM: | 1 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, HTTP, HTTPS, TFTP, SSH-2, CLI, SFTP, JSON, LDAP |
| Routing Protocol: | IGMPv2, IGMP, IGMPv3, static IPv4 routing |
| Status Indicators: | Power, system, link/activity, virtual chassis |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Weight: | 3.8 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
|---|---|
| GPSR - product manufacturer: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
| GPSR - EU responsible person: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
| EU Data-Act-Url: | https://www.al-enterprise.com/de-de/rechtliches/compliance-regeln |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
Fixed 1RU chassis 24 RJ 45 PoE 10/100/1G BaseT 2 10G SFP+ uplink ports 2 SFP(+) as 1G uplinks 10G stacking 370W power budget
| Authentication Method: | RADIUS, TACACS+, Secure Shell v.2 (SSH2), LDAP, Extensible Authentication Protocol (EAP) |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 1024 ¦ IPv4 routes (static): 32 ¦ IPv4 interfaces: 24 ¦ Multicast groups: 1000 |
| Compliant Standards: | C-Tick, EN 61000-3-2, EN55022, EN 61000-3-3, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EMC, EN 61000-4-5, EN 61000-4-11, RoHS, EN 61000-4-8, IEC 60950-1, UL 60950-1 Second Edition, WEEE, ANATEL, EN 60825-1, AS/NZS 3548 Class A, AS/NZS 6, IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.3ak, IEEE 802.1ab (LLDP), I |
| Depth: | 30 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | MD5, PKI, ESP, HMAC |
| Features: | Flow control, DHCP support, auto-negotiation, BOOTP support, ARP support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP |
| Flash Memory: | 512 MB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE+ ¦ 2 x 10Gbit LANSFP+ uplink ¦ 2 x Gigabit / 10Gbit LANSFP+ uplink/stacking ¦ 1 x console RJ-45 ¦ 1 x USB Type A management |
| Jumbo Frame Support: | 12KB |
| Localisation: | Europe |
| MAC Address Table Size: | 16K entries |
| MTBF: | 693,000 hours |
| Manufacturer: | Alcatel-Lucent Nokia |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 60 °C |
| Max Units In A Stack: | 4 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -20 °C |
| Performance: | Latency: 4 µs ¦ Switching ASIC capacity: 128 Gbps ¦ Switching capacity (full duplex): 128 Gbps ¦ Frame rate: 95.2 Mpps ¦ Maximum virtual chassis interconnect capacity: 40 Gbps |
| PoE Budget: | 370 W |
| Ports: | 24 x 10/100/1000 (PoE+) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) |
| Power Consumption Operational: | 40.2 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| Processor: | 1 x MIPS: 1 GHz |
| RAM: | 1 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, HTTP, HTTPS, TFTP, SSH-2, CLI, SFTP, JSON, LDAP |
| Routing Protocol: | IGMPv2, IGMP, IGMPv3, static IPv4 routing |
| Status Indicators: | Power, system, link/activity, virtual chassis |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Weight: | 3.8 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
|---|---|
| GPSR - product manufacturer: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
| GPSR - EU responsible person: | Alcatel-Lucent, Deutschland, Stammheimer Str. 10 Haus 6, 3. OG, Kornwestheim, 70806, enterprise.solutions@al-enterprise.com |
| EU Data-Act-Url: | https://www.al-enterprise.com/de-de/rechtliches/compliance-regeln |
