Aruba J9575A
HP 3800-24G-2SFP+ Switch
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
HP 3800-24G-2SFP+ Switch
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Compliant Standards: | FCC Class A certified, CISPR 24, EN 61000-3-2, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, UL 60950, CSA 22.2 No. 60950, RoHS, IEC 60950-1, EN 60950-1, EN 60825 |
| Depth: | 46.7 cm |
| Device Type: | Switch - 24 ports - L4 - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | SSL |
| Expansion Slots: | 1 (total) / 1 (free) x Stacking Module |
| Features: | Flow control, Layer 2 switching, DHCP support, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, IPv6 support, sFlow, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VR |
| Flash Memory: | 4 GB |
| Height: | 4.3 cm |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 90% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x 10Gb Ethernet / 1Gb Ethernet - SFP+ ¦ 1 x console RJ-45 management ¦ 1 x RJ-45 management |
| Jumbo Frame Support: | Yes |
| MAC Address Table Size: | 65K entries |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 55 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Throughput: 65.4 Mpps ¦ Switching capacity: 88 Gbps |
| Ports: | 24 x 10/100/1000 + 2 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Processor: | 2 |
| RAM: | 2 GB SDRAM |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI |
| Routing Protocol: | OSPF, RIP-1, RIP-2, IGMP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, OSPFv3, MLDv2, MLD |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 6.9 kg |
| Width: | 44.3 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
