| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Authentication Method: | RADIUS, PAP, CHAP, TACACS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Capacity: | IPv4 routing table entries: 2048 ¦ IPv6 routing table entries: 256 |
| Compliant Standards: | C-Tick, GOST, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN55024, EN55022 Class A, FCC Part 15 B, ICES-003 Class A, RoHS, EN 60950-1, IEC 60825-1, EN 60, IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1v, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
| Depth: | 33.6 cm |
| Device Type: | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | SSL, TLS |
| Expansion Slots: | 2 (total) / 2 (free) x Expansion Slot ¦ 1 (total) / 1 (free) x Stacking Module |
| Features: | Flow control, DHCP support, BOOTP support, ARP support, trunking, VLAN support, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (Q |
| Flash Memory: | 1 GB |
| Height: | 4.39 cm |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 90% (non-condensing) |
| Interfaces: | 48 x Gigabit LAN 10Base-T/100Base-TX/1000Base-T - RJ-45 PoE+ - 30 W ¦ 4 x SFP (mini-GBIC) - SFP ¦ 1 x RJ-45 ¦ 1 x micro-USB Type B ¦ Management: 1 x USB USB - 4 pin USB Type A ¦ 1 x management RJ-45 |
| Jumbo Frame Support: | 9220 bytes |
| MAC Address Table Size: | 16000 entries |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 55 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Throughput: 130.9 Mpps ¦ Switching capacity: 176 Gbps |
| PoE Budget: | 370 W |
| Ports: | 44 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP (PoE+) |
| Power Consumption Operational: | 487 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| Power Provided: | 575 Watt |
| Processor: | 1 x ARM ARM1176: 625 MHz |
| RAM: | 512 MB SDRAM |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SMON, SSH, SSH-2, CLI |
| Routing Protocol: | RIP, RIP-2, static IP routing, MLD |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 5.7 kg |
| Width: | 44.25 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
