Aruba JH390A
HPE FlexFabric 5940 48SFP+ 6QSFP28 Switch
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
HPE FlexFabric 5940 48SFP+ 6QSFP28 Switch
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Capacity: | IPv4 routing table entries: 120000 ¦ IPv6 routing table entries: 60000 |
| Compliant Standards: | CISPR 22 Class A, GOST, NOM, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, ANATEL, UL-AR, EN 60825-1, ANSI C63.4-2003, EN 60825-2, VCCI Class A, EN 61000-3-3:1995+A1:2001+A2:2005, EMC 2004/108/EC, EN 55022 Class A, FCC CFR47 Part 15 A, EN 60950-1/A11, |
| Depth: | 46 cm |
| Device Type: | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Features: | Flow control, DHCP support, port mirroring, IPv6 support, Weighted Fair Queuing (WFQ), Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Device Link De |
| Flash Memory: | 1 GB |
| Height: | 4.36 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 48 x Gigabit / 10Gbit LAN SFP+ ¦ 6 x 100Gbit LAN QSFP28 ¦ 1 x serial (console) RJ-45 ¦ 1 x management (LAN) RJ-45 ¦ 1 x USB 2.0 |
| Jumbo Frame Support: | Yes |
| MAC Address Table Size: | 288K entries |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 45 °C |
| Max Units In A Stack: | 9 |
| Min Operating Temperature: | 0 °C |
| Performance: | Routing/switching capacity: 2160 Gbps ¦ Latency (10 Gbps): < 1 µs |
| Ports: | 48 x 1 Gigabit / 10 Gigabit SFP+ + 6 x 100 Gigabit QSFP28 |
| Power Device: | Internal power supply |
| RAM: | 4 GB SDRAM |
| Remote Management Protocol: | SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, SSH-2, CLI |
| Routing Protocol: | OSPF, BGP-4, IS-IS, RIP-1, RIP-2, IGMP, VRRP, OSPFv2, OSPFv3, static IPv6 routing, RIPng, IS-ISv6, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD) |
| Subtype: | 100 Gigabit Ethernet |
| Version: | original |
| Weight: | 11 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
