Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Capacity: | Virtual interfaces (VLANs): 1023 |
| Compliant Standards: | GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 17.7 cm |
| Device Type: | Switch - 8 ports - Managed |
| Enclosure Type: | Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
| Features: | Full duplex capability, DHCP support, auto-negotiation, BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Trivial File T |
| Flash Memory: | 128 MB |
| Height: | 4.44 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Interfaces: | 8 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-T RJ-45 UPOE ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 1 x console RJ-45 |
| Jumbo Frame Support: | 9198 bytes |
| MTBF: | 737,740 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | -5 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance (64-byte packet size): 14.9 Mpps |
| PoE Budget: | 146 W |
| Ports: | 10 x 10/100/1000 (PoE+) |
| Power Consumption Operational: | 24.3 Watt |
| Power Over Ethernet (PoE): | PoE+ |
| RAM: | 512 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Routing Protocol: | RIP-1, RIP-2, static IP routing |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port transmission speed, system, status, PoE, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Weight: | 1.58 kg |
| Width: | 26.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Capacity: | Virtual interfaces (VLANs): 1023 |
| Compliant Standards: | GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 17.7 cm |
| Device Type: | Switch - 8 ports - Managed |
| Enclosure Type: | Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
| Features: | Full duplex capability, DHCP support, auto-negotiation, BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Trivial File T |
| Flash Memory: | 128 MB |
| Height: | 4.44 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Interfaces: | 8 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-T RJ-45 UPOE ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 1 x console RJ-45 |
| Jumbo Frame Support: | 9198 bytes |
| MTBF: | 737,740 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | -5 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance (64-byte packet size): 14.9 Mpps |
| PoE Budget: | 146 W |
| Ports: | 10 x 10/100/1000 (PoE+) |
| Power Consumption Operational: | 24.3 Watt |
| Power Over Ethernet (PoE): | PoE+ |
| RAM: | 512 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Routing Protocol: | RIP-1, RIP-2, static IP routing |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port transmission speed, system, status, PoE, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Weight: | 1.58 kg |
| Width: | 26.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
Luca-Eric Junghans is your contact person for:
