Cisco WS-C4500X-32SFP+
Catalyst 4500-X 32 Port 10G IP Base, Front-to-Back, No P/S
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Catalyst 4500-X 32 Port 10G IP Base, Front-to-Back, No P/S
| Capacity: | IPv4 forwarding table entries: 256000 ¦ IPv6 forwarding table entries: 128000 ¦ NetFlow entries: 128000 ¦ Virtual interfaces (VLANs): 4094 ¦ IGMP groups: 32000 ¦ Multicast entries (IPv4): 32000 ¦ Multicast entries (IPv6): 32000 ¦ ARP entries: 47000 ¦ Span |
|---|---|
| Compliant Standards: | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, AS/NZS, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Sec |
| Device Type: | Switch - 32 ports |
| Enclosure Type: | Front to back airflow rack-mountable |
| Expansion Slots: | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x Expansion Slot |
| Features: | Layer 2 switching, VLAN support, Access Control List (ACL) support, Quality of Service (QoS), redundant hot swappable fans |
| Flash Memory: | 2 GB (max) |
| Interfaces: | 32 x 10Gb Ethernet / 1Gb Ethernet - SFP/SFP+ ¦ 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 management ¦ 1 x USB Type A ¦ 1 x console - RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 55K entries |
| MTBF: | 199,720 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Throughput: 800 Gbps ¦ IPv4 routing: 250 Mpps ¦ IPv6 routing: 125 Mpps |
| Ports: | 32 x 10 Gigabit SFP+ |
| Power Consumption Operational: | 330 Watt |
| Power Device: | Internal power supply (not installed) - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Processor: | : 1.5 GHz |
| RAM: | 4 GB DDR2 SDRAM |
| Remote Management Protocol: | RMON 1, RMON 2 |
| Software Included: | Cisco IOS IP Base |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
Catalyst 4500-X 32 Port 10G IP Base, Front-to-Back, No P/S
| Capacity: | IPv4 forwarding table entries: 256000 ¦ IPv6 forwarding table entries: 128000 ¦ NetFlow entries: 128000 ¦ Virtual interfaces (VLANs): 4094 ¦ IGMP groups: 32000 ¦ Multicast entries (IPv4): 32000 ¦ Multicast entries (IPv6): 32000 ¦ ARP entries: 47000 ¦ Span |
|---|---|
| Compliant Standards: | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, AS/NZS, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Sec |
| Device Type: | Switch - 32 ports |
| Enclosure Type: | Front to back airflow rack-mountable |
| Expansion Slots: | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x Expansion Slot |
| Features: | Layer 2 switching, VLAN support, Access Control List (ACL) support, Quality of Service (QoS), redundant hot swappable fans |
| Flash Memory: | 2 GB (max) |
| Interfaces: | 32 x 10Gb Ethernet / 1Gb Ethernet - SFP/SFP+ ¦ 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 management ¦ 1 x USB Type A ¦ 1 x console - RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 55K entries |
| MTBF: | 199,720 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Throughput: 800 Gbps ¦ IPv4 routing: 250 Mpps ¦ IPv6 routing: 125 Mpps |
| Ports: | 32 x 10 Gigabit SFP+ |
| Power Consumption Operational: | 330 Watt |
| Power Device: | Internal power supply (not installed) - hot-plug |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Processor: | : 1.5 GHz |
| RAM: | 4 GB DDR2 SDRAM |
| Remote Management Protocol: | RMON 1, RMON 2 |
| Software Included: | Cisco IOS IP Base |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
