X440-G2 24 10/100/1000BASE-T POE+, 4 SFP combo, 4 1GbE unpopulated SFP upgradable to 10GbE SFP+, 1 Fixed AC PSU, 1 RPS port, ExtremeXOS Edge license
| Capacity: | Virtual interfaces (VLANs): 4094 ¦ QoShardware queues per port: 8 |
|---|---|
| Compliant Standards: | CISPR 22 Class A, CISPR 24, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, FCC, EN 61000-4-11, RoHS, CSA C22.2 No. 60950-1-03, UL 60950, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az |
| Depth: | 25.4 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Features: | Traffic shaping, DoS attack prevention, CLEAR-Flow Security Rules Engine, 1.5MB packet buffer |
| Features: | Redundant Power System (RPS) connector |
| Flash Memory: | 4 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 95% (non-condensing) |
| Humidity Range Storage: | 10 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 8 x 10GBase-X SFP+ ¦ 1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 16K entries |
| Manufacturer: | Extreme |
| Max Operating Temperature: | 50 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Aggregate switching bandwidth: 128 Gbps ¦ Forwarding performance: 95.2 Mpps ¦ Latency (64-byte packets): 4 µs |
| Ports: | 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ + 4 x combo SFP |
| Power Consumption Operational: | 500 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | PoE+ |
| Power Redundancy: | Optional |
| Processor: | X MIPS: 1 GHz |
| RAM: | 1 GB DDR3 SDRAM |
| Software Included: | ExtremeXOS Edge |
| Status Indicators: | Port status, power, fan |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 4.28 kg |
| Width: | 44.1 cm |
| GPSR - economic actor: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
|---|---|
| GPSR - product manufacturer: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
| GPSR - EU responsible person: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
| EU Data-Act-Url: | https://www.extremenetworks.com/support/policies |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
X440-G2 24 10/100/1000BASE-T POE+, 4 SFP combo, 4 1GbE unpopulated SFP upgradable to 10GbE SFP+, 1 Fixed AC PSU, 1 RPS port, ExtremeXOS Edge license
| Capacity: | Virtual interfaces (VLANs): 4094 ¦ QoShardware queues per port: 8 |
|---|---|
| Compliant Standards: | CISPR 22 Class A, CISPR 24, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, FCC, EN 61000-4-11, RoHS, CSA C22.2 No. 60950-1-03, UL 60950, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az |
| Depth: | 25.4 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Features: | Traffic shaping, DoS attack prevention, CLEAR-Flow Security Rules Engine, 1.5MB packet buffer |
| Features: | Redundant Power System (RPS) connector |
| Flash Memory: | 4 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 95% (non-condensing) |
| Humidity Range Storage: | 10 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 8 x 10GBase-X SFP+ ¦ 1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 16K entries |
| Manufacturer: | Extreme |
| Max Operating Temperature: | 50 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Aggregate switching bandwidth: 128 Gbps ¦ Forwarding performance: 95.2 Mpps ¦ Latency (64-byte packets): 4 µs |
| Ports: | 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ + 4 x combo SFP |
| Power Consumption Operational: | 500 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | PoE+ |
| Power Redundancy: | Optional |
| Processor: | X MIPS: 1 GHz |
| RAM: | 1 GB DDR3 SDRAM |
| Software Included: | ExtremeXOS Edge |
| Status Indicators: | Port status, power, fan |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 4.28 kg |
| Width: | 44.1 cm |
| GPSR - economic actor: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
|---|---|
| GPSR - product manufacturer: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
| GPSR - EU responsible person: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de@extremenetworks.com |
| EU Data-Act-Url: | https://www.extremenetworks.com/support/policies |
