Extreme X465-24MU-B1
ExtremeSwitching X465-24MU Bundle includes X465-24MU and one 1100W AC PSU FB (10941)
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
ExtremeSwitching X465-24MU Bundle includes X465-24MU and one 1100W AC PSU FB (10941)
| Compliant Standards: | BSMI, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, SABS, EN55024, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, |
|---|---|
| Depth: | 48.8 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | 128-bit AES, 256-bit AES |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Routing, MPLS support, sFlow, redundant hot swappable fans, Virtual Private LAN Service (VPLS), VXLAN tunnel endpoints (VTEP) support, Priority-Based Flow Control (PFC), Virtual Extensible LAN (VXLAN), 2 fan trays, non-blocking traffic forwarding |
| Features: | Front-to-rear airflow |
| Flash Memory: | 8 GB |
| Height: | 4.36 cm |
| Humidity Range Operating: | 10 - 95% (non-condensing) |
| Humidity Range Storage: | 10 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 5Gbit LAN RJ-45 UPOE - 60 W ¦ 2 x 40GBase-X QSFP+ stacking ¦ 1 x serial (console) RJ-45 management ¦ 1 x 1000Base-T RJ-45 management ¦ 1 x micro-USB Type B console ¦ 2 x USB Type A |
| MAC Address Table Size: | 272K entries |
| Manufacturer: | Extreme |
| Max Operating Temperature: | 50 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Max Units In A Stack: | 8 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Aggregate switching bandwidth: 648 Gbps ¦ Stacking bandwidth: 482.1 Mpps |
| PoE Budget: | 825 W |
| Ports: | 24 x 100/1000/2.5G/5GBase-T (UPOE) + 2 x 40 Gigabit QSFP+ (stacking) |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | UPOE |
| Power Provided: | 1100 Watt |
| Power Redundancy: | Optional |
| Processor: | 1 |
| RAM: | 8 GB SDRAM |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | CLI |
| Routing Protocol: | OSPF, RIP, BGP, PIM-SM, static IP routing |
| Software Included: | ExtremeWare XOS Advanced Edge |
| Status Indicators: | Port status, power, fan |
| Subtype: | 5 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 7.94 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
|---|---|
| GPSR - product manufacturer: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
| GPSR - EU responsible person: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
ExtremeSwitching X465-24MU Bundle includes X465-24MU and one 1100W AC PSU FB (10941)
| Compliant Standards: | BSMI, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, SABS, EN55024, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, |
|---|---|
| Depth: | 48.8 cm |
| Device Type: | Switch - 24 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | 128-bit AES, 256-bit AES |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Routing, MPLS support, sFlow, redundant hot swappable fans, Virtual Private LAN Service (VPLS), VXLAN tunnel endpoints (VTEP) support, Priority-Based Flow Control (PFC), Virtual Extensible LAN (VXLAN), 2 fan trays, non-blocking traffic forwarding |
| Features: | Front-to-rear airflow |
| Flash Memory: | 8 GB |
| Height: | 4.36 cm |
| Humidity Range Operating: | 10 - 95% (non-condensing) |
| Humidity Range Storage: | 10 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 5Gbit LAN RJ-45 UPOE - 60 W ¦ 2 x 40GBase-X QSFP+ stacking ¦ 1 x serial (console) RJ-45 management ¦ 1 x 1000Base-T RJ-45 management ¦ 1 x micro-USB Type B console ¦ 2 x USB Type A |
| MAC Address Table Size: | 272K entries |
| Manufacturer: | Extreme |
| Max Operating Temperature: | 50 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Max Units In A Stack: | 8 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Aggregate switching bandwidth: 648 Gbps ¦ Stacking bandwidth: 482.1 Mpps |
| PoE Budget: | 825 W |
| Ports: | 24 x 100/1000/2.5G/5GBase-T (UPOE) + 2 x 40 Gigabit QSFP+ (stacking) |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | UPOE |
| Power Provided: | 1100 Watt |
| Power Redundancy: | Optional |
| Processor: | 1 |
| RAM: | 8 GB SDRAM |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | CLI |
| Routing Protocol: | OSPF, RIP, BGP, PIM-SM, static IP routing |
| Software Included: | ExtremeWare XOS Advanced Edge |
| Status Indicators: | Port status, power, fan |
| Subtype: | 5 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 7.94 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
|---|---|
| GPSR - product manufacturer: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
| GPSR - EU responsible person: | Extreme Networks, Deutschland, Solmsstraße 83, Frankfurt am Main, 60486, Info.de @ extremenetworks.com |
