HPE JG708A
HP 1410-24G-R Switch
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
HP 1410-24G-R Switch
| Compliant Standards: | CISPR 24, EN55022, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN55024, CISPR 22, CSA 22.2 No. 60950, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 B Class A |
|---|---|
| Depth: | 17.3 cm |
| Device Type: | Switch - 24 ports - unmanaged |
| Electric Current Required: | 300 mA |
| Enclosure Type: | Desktop, rack-mountable 1U |
| Features: | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, Quality of Service (QoS), Jumbo Frames support, fanless, Mini Jumbo Frame support, Type of Service (ToS), DiffServ Code Point (DSCP) support |
| Flash Memory: | 1 MB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Humidity Range Storage: | 5 - 90% (non-condensing) |
| Interfaces: | 24 x 1000Base-T RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 8192 entries |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching capacity: 48 Gbps ¦ Throughput: 35.7 Mpps |
| Ports: | 24 x 10/100/1000 |
| Power Consumption Operational: | 16 Watt |
| Power Device: | Internal power supply |
| Rack Mounting Kit: | Included |
| Status Indicators: | Port transmission speed, port duplex mode, status, link/activity |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 3 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
|---|---|
| : | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden @ hpe.com |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
