| Authentication Method: | RADIUS, PAP, CHAP, TACACS, TACACS+ |
|---|---|
| Capacity: | Jumbo frame size: 9220 ¦ IPv4 routing table entries: 10000 ¦ IPv6 routing table entries: 5000 |
| Compliant Standards: | CISPR 22 Class A, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition, VCCI, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
| Depth: | 25.4 cm |
| Device Type: | Switch - 8 ports - L3 - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | MD5, SSL |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Multiple Spanning Tree Protocol (MSTP) |
| Flash Memory: | 4 GB |
| Height: | 4.39 cm |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 90% (non-condensing) |
| Included Accessories: | 4 rubber feet, rack mount kit, mounting screws, table mounting kit |
| Installed Modules Qty (Max): | 0 (installed) / 2 (max) |
| Installed Qty: | 1 |
| Interfaces: | 8 x 1000Base-T RJ-45 PoE+ ¦ 2 x Gigabit / 10Gbit LANSFP+ ¦ 1 x serial (console) |
| MAC Address Table Size: | 32K entries |
| Manufacturer: | Aruba HPE |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Throughput: 41.7 Mpps ¦ Switching capacity: 56 Gbps ¦ Latency (1 Gbps): 3.8 µs ¦ Latency (10 Gbps): 1.6 µs |
| PoE Budget: | 125 W |
| Ports: | 8 x 10/100/1000 (PoE+) + 2 x 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Power Device: | External power adapter |
| Power Over Ethernet (PoE): | PoE+ |
| Processor: | 1 x ARM Cortex-A9: 1.016 GHz |
| RAM: | 1 GB DDR3 SDRAM |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON |
| Routing Protocol: | OSPF, RIP, RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR |
| Software Included: | Command Line Interface (CLI), HP Web browser, HP Intelligent Management Center |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 90-264 V |
| Weight: | 2 kg |
| Width: | 25.4 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
