Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| Authentication Method: | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 4093 ¦ VLAN Spanning Tree Protocol instances: 510 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ ARP entries: 64000 ¦ IPv4 routes: 32000 ¦ Maximum of neighbouring networks: 32000 ¦ IPv6 routes: 15000 |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.1ak,, TUV GS, CISPR 22 Class A, cUL, EN55024, EMC, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, NEBS, ISO 7779, GR-1089-CORE, VCCI Class A, EN 60950-1:2006, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1 |
| Depth: | 46.7 cm |
| Device Type: | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, TLS, PEAP, TTLS |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Flow control, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, DiffServ support, store and forward, IPv6 support, High Availability, ASIC VPN, SNTP support, DDos attack prevention, |
| Flash Memory: | 64 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Humidity Range Storage: | 0 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE++ - 95 W ¦ 24 x 10GBase-T RJ-45 PoE++ - 95 W ¦ 1 x mini-USB management |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 64K entries |
| Manufacturer: | Juniper HPE |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Max Units In A Stack: | 10 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching capacity: 960 Gbps ¦ Throughput: 714 Mpps |
| PoE Budget: | 1100 W |
| Ports: | 24 x 10/100/1000 + 24 x 100/1000/2.5G/5G/10GBase-T (PoE++) |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | PoE+ |
| Power Provided: | 1400 Watt |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Processor: | 1 x Intel: 2.2 GHz |
| RAM: | 8 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI |
| Routing Protocol: | OSPF, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, OSPFv3, PIM-SSM, static IPv4 routing, static IPv6 routing, RIPng, MPLS, Bidirectional Forwarding Detection (BFD), VRRPv3, CIDR |
| Status Indicators: | System, alarm, PoE, link/speed |
| Subtype: | 10 Gigabit Ethernet |
| TAA Compliant: | Yes |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 7.3 kg |
| Width: | 44.1 cm |
| GPSR - economic actor: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
|---|---|
| GPSR - product manufacturer: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| GPSR - EU responsible person: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| EU Data-Act-Url: | https://www.juniper.net/us/en/privacy-policy/european-privacy-policy.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| Authentication Method: | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 4093 ¦ VLAN Spanning Tree Protocol instances: 510 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ ARP entries: 64000 ¦ IPv4 routes: 32000 ¦ Maximum of neighbouring networks: 32000 ¦ IPv6 routes: 15000 |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.1ak,, TUV GS, CISPR 22 Class A, cUL, EN55024, EMC, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, NEBS, ISO 7779, GR-1089-CORE, VCCI Class A, EN 60950-1:2006, EN 55022 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1 |
| Depth: | 46.7 cm |
| Device Type: | Switch - 48 ports - L3 - Managed - stackable |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, TLS, PEAP, TTLS |
| Expansion Slots: | 1 (total) / 1 (free) x Expansion Slot |
| Features: | Flow control, BOOTP support, RARP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, DiffServ support, store and forward, IPv6 support, High Availability, ASIC VPN, SNTP support, DDos attack prevention, |
| Flash Memory: | 64 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Humidity Range Storage: | 0 - 95% (non-condensing) |
| Installed Qty: | 1 |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE++ - 95 W ¦ 24 x 10GBase-T RJ-45 PoE++ - 95 W ¦ 1 x mini-USB management |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 64K entries |
| Manufacturer: | Juniper HPE |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Max Units In A Stack: | 10 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching capacity: 960 Gbps ¦ Throughput: 714 Mpps |
| PoE Budget: | 1100 W |
| Ports: | 24 x 10/100/1000 + 24 x 100/1000/2.5G/5G/10GBase-T (PoE++) |
| Power Device: | Internal power supply - hot-plug |
| Power Over Ethernet (PoE): | PoE+ |
| Power Provided: | 1400 Watt |
| Power Redundancy: | Optional |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Processor: | 1 x Intel: 2.2 GHz |
| RAM: | 8 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS, SSH, SSH-2, CLI |
| Routing Protocol: | OSPF, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, OSPFv3, PIM-SSM, static IPv4 routing, static IPv6 routing, RIPng, MPLS, Bidirectional Forwarding Detection (BFD), VRRPv3, CIDR |
| Status Indicators: | System, alarm, PoE, link/speed |
| Subtype: | 10 Gigabit Ethernet |
| TAA Compliant: | Yes |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 7.3 kg |
| Width: | 44.1 cm |
| GPSR - economic actor: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
|---|---|
| GPSR - product manufacturer: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| GPSR - EU responsible person: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| EU Data-Act-Url: | https://www.juniper.net/us/en/privacy-policy/european-privacy-policy.html |
