| Authentication Method: | RADIUS |
|---|---|
| Built-in Devices: | 1.3" touch screen display |
| Compliant Standards: | FCC, IC, ETSI 300 019-1-4, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1x |
| Depth: | 39.96 cm |
| Device Type: | Switch - 48 ports - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Features: | 12KV ESD Protector, Inter-VLAN Routing, DHCP server, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control |
| Height: | 4.37 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 40 x 1000Base-T RJ-45 PoE+ - 32 W ¦ 8 x 1000Base-T RJ-45 PoE++ - 64 W ¦ 4 x 1/10Gbit LAN SFP+ ¦ 1 x management |
| Manufacturer: | Ubiquiti |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | -5 °C |
| Performance: | Non-blocking bandwidth: 88 Gbps ¦ Switching capacity: 176 Gbps ¦ Forwarding rate: 130.944 Mpps |
| <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="Using PoE (Power over Ethernet), network cables can supply devices with data and power via an existing data connection. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">PoE</a> Budget: | 600 W |
| <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="A port is part of the IP address. Ports are used to communicate between 2 or more computers with the Internet. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">Ports</a>: | 48 x 10/100/1000 (40 PoE+, 8 PoE++) + 4 x 10Gb Ethernet SFP+ |
| Power Consumption Operational: | 60 Watt |
| Power Device: | Internal power supply |
| Power Over <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="An Ethernet is a wired data network that connects hardware/software. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">Ethernet</a> (<a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="Using PoE (Power over Ethernet), network cables can supply devices with data and power via an existing data connection. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">PoE</a>): | PoE++ |
| Power Provided: | 600 Watt |
| Status Indicators: | Status, PoE, link/activity/speed, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V / DC 11.5/52 V (50/60 Hz) |
| Weight: | 6.25 kg |
| Width: | 44.24 cm |
| GPSR - product manufacturer: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
|---|---|
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| Authentication Method: | RADIUS |
|---|---|
| Built-in Devices: | 1.3" touch screen display |
| Compliant Standards: | FCC, IC, ETSI 300 019-1-4, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1x |
| Depth: | 39.96 cm |
| Device Type: | Switch - 48 ports - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Features: | 12KV ESD Protector, Inter-VLAN Routing, DHCP server, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control |
| Height: | 4.37 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 40 x 1000Base-T RJ-45 PoE+ - 32 W ¦ 8 x 1000Base-T RJ-45 PoE++ - 64 W ¦ 4 x 1/10Gbit LAN SFP+ ¦ 1 x management |
| Manufacturer: | Ubiquiti |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | -5 °C |
| Performance: | Non-blocking bandwidth: 88 Gbps ¦ Switching capacity: 176 Gbps ¦ Forwarding rate: 130.944 Mpps |
| <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="Using PoE (Power over Ethernet), network cables can supply devices with data and power via an existing data connection. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">PoE</a> Budget: | 600 W |
| <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="A port is part of the IP address. Ports are used to communicate between 2 or more computers with the Internet. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">Ports</a>: | 48 x 10/100/1000 (40 PoE+, 8 PoE++) + 4 x 10Gb Ethernet SFP+ |
| Power Consumption Operational: | 60 Watt |
| Power Device: | Internal power supply |
| Power Over <a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="An Ethernet is a wired data network that connects hardware/software. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">Ethernet</a> (<a class="lexicon-tooltip cbax-lexicon-link" data-bs-toggle="tooltip" title="Using PoE (Power over Ethernet), network cables can supply devices with data and power via an existing data connection. " data-bs-placement="top" data-bs-html="true" data-bs-template="<div class='tooltip' role='tooltip'><div class='arrow'></div><div class='tooltip-inner cbax-lexicon-tooltip-inner'></div></div>">PoE</a>): | PoE++ |
| Power Provided: | 600 Watt |
| Status Indicators: | Status, PoE, link/activity/speed, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V / DC 11.5/52 V (50/60 Hz) |
| Weight: | 6.25 kg |
| Width: | 44.24 cm |
| GPSR - product manufacturer: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
|---|
