Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| Authentication Method: | RADIUS |
|---|---|
| Built-in Devices: | 1.3" touch screen display |
| Compliant Standards: | FCC, IC, ETSI 300 019-1-4, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1x |
| Depth: | 39.96 cm |
| Device Type: | Switch - 48 ports - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Features: | 12KV ESD Protector, Inter-VLAN Routing, DHCPserver, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control |
| Height: | 4.37 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 40 x 1000Base-T RJ-45 PoE+ - 32 W ¦ 8 x 1000Base-T RJ-45 PoE++ - 64 W ¦ 4 x 1/10Gbit LANSFP+ ¦ 1 x management |
| Manufacturer: | Ubiquiti |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | -5 °C |
| Performance: | Non-blocking bandwidth: 88 Gbps ¦ Switching capacity: 176 Gbps ¦ Forwarding rate: 130.944 Mpps |
| PoE Budget: | 600 W |
| Ports: | 48 x 10/100/1000 (40 PoE+, 8 PoE++) + 4 x 10Gb EthernetSFP+ |
| Power Consumption Operational: | 60 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE++ |
| Power Provided: | 600 Watt |
| Status Indicators: | Status, PoE, link/activity/speed, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V / DC 11.5/52 V (50/60 Hz) |
| Weight: | 6.25 kg |
| Width: | 44.24 cm |
| GPSR - economic actor: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
|---|---|
| GPSR - product manufacturer: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
| GPSR - EU responsible person: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
| EU Data-Act-Url: | https://www.ui.com/legal/privacypolicy/ |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| Authentication Method: | RADIUS |
|---|---|
| Built-in Devices: | 1.3" touch screen display |
| Compliant Standards: | FCC, IC, ETSI 300 019-1-4, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.1x |
| Depth: | 39.96 cm |
| Device Type: | Switch - 48 ports - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Features: | 12KV ESD Protector, Inter-VLAN Routing, DHCPserver, GVRP, auto-uplink (auto MDI/MDI-X), switching, port mirroring, aggregation mode, Jumbo Frames support, flow control, DPI, Storm Control |
| Height: | 4.37 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Interfaces: | 40 x 1000Base-T RJ-45 PoE+ - 32 W ¦ 8 x 1000Base-T RJ-45 PoE++ - 64 W ¦ 4 x 1/10Gbit LANSFP+ ¦ 1 x management |
| Manufacturer: | Ubiquiti |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | -5 °C |
| Performance: | Non-blocking bandwidth: 88 Gbps ¦ Switching capacity: 176 Gbps ¦ Forwarding rate: 130.944 Mpps |
| PoE Budget: | 600 W |
| Ports: | 48 x 10/100/1000 (40 PoE+, 8 PoE++) + 4 x 10Gb EthernetSFP+ |
| Power Consumption Operational: | 60 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE++ |
| Power Provided: | 600 Watt |
| Status Indicators: | Status, PoE, link/activity/speed, link/activity |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V / DC 11.5/52 V (50/60 Hz) |
| Weight: | 6.25 kg |
| Width: | 44.24 cm |
| GPSR - economic actor: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
|---|---|
| GPSR - product manufacturer: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
| GPSR - EU responsible person: | Ubiquiti International Holding B.V., Niederlande, Ekkersrijt 3102, Son En Breugel, 5692, support@ubnt.com |
| EU Data-Act-Url: | https://www.ui.com/legal/privacypolicy/ |
