Fortinet FAP-432F
Fortinet FortiAP 432F - Wireless access point - ZigBee - Bluetooth, ZigBee, Wi-Fi 6 - 2.4 GHz, 5 GHz
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Fortinet FortiAP 432F - Wireless access point - ZigBee - Bluetooth, ZigBee, Wi-Fi 6 - 2.4 GHz, 5 GHz
| Antenna: | External |
|---|---|
| Antenna Qty: | 6 |
| Authentication Method: | Radio Service Set ID (SSID), MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA, EAP-GTC, EAP-TLS, EAP-TTLS |
| Capacity: | Maximum number of configured SSIDs: 16 ¦ Wireless clients per Wi-Fi radio: up to 512 |
| Communications Technology: | Bluetooth Low Energy (LE), Zigbee |
| Compliant Standards: | RoHS, IP67, LVD |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11j, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v, IEEE 802.11a |
| Connectivity Technology: | Wireless |
| Data Link Protocol: | Bluetooth LE, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6) |
| Depth: | 20.9 cm |
| Device Type: | Radio access point |
| Directivity: | Omni-directional |
| Encryption Algorithm: | PEAP, WPA, WPA2, WEP, EAP-SIM, EAP-AKA, WPA3, EAP-FAST, EAP-TLS, EAP-TTLS, MSCHAPv2, EAP-GTC |
| Features: | DFS support, surge protection, Wireless Intrusion Detection System (WIDS), LACP support, Wireless Intrusion Prevention System (WIPS), 802.1x authentication, iBeacon technology, LED off mode, spectrum analyser, Packet Sniffer Mode, security slot (Kensingto |
| Form Factor: | External |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Height: | 6.05 cm |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Included Accessories: | Wall/ceiling/T-Rall mounting kit |
| Interfaces: | 1 x 1/2.5GBase-T (PoE+) - RJ-45 ¦ 1 x 1000Base-T (PoE output) - RJ-45 ¦ 1 x management (RS-232) - RJ-45 ¦ 1 x USB - Type A ¦ 6 x aerial - N connector |
| Internet of Things (IoT) Compatible: | Yes |
| Line Coding Format: | 64 QAM, 256 QAM, BPSK, QPSK, 1024 QAM, OFDMA |
| MTBF: | >10 years |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 60 °C |
| Min Operating Temperature: | -30 °C |
| Performance: | Maximum throughput (2.4 GHz): 1147 Mbps ¦ Maximum throughput (5 GHz): 2402 Mbps |
| Power Consumption Operational: | 37.9 Watt |
| Power Over Ethernet (PoE) Supported: | PoE+ |
| Ruggedized Design: | Outdoor |
| Shipping Weight: | 5.7 kg |
| Spread Spectrum Method: | OFDMA |
| Version: | original |
| Weight: | 2.325 kg |
| Width: | 20.9 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs @ fortinet.com |
| Warnings: | Warnings Accesspoints International.pdf |
| Safety instructions: | Safety instructions Accesspoints International.pdf |
