HPE R4W53A
HPE Aruba AP-565 (RW) TAA Outdoor 11ax AP (R4W53A)
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
HPE Aruba AP-565 (RW) TAA Outdoor 11ax AP (R4W53A)
| Antenna: | Internal |
|---|---|
| Capacity: | Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 16 |
| Communications Technology: | Bluetooth Low Energy (LE), Zigbee |
| Compliant Standards: | CB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU |
| Connectivity Technology: | Wireless |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
| Data Transfer Rate: | 1.49 Gbps |
| Depth: | 16.5 cm |
| Device Type: | Radio access point |
| Directivity: | Omni-directional |
| Encryption Algorithm: | WPA3-Enhanced Open, WPA2-MPSK |
| Features: | Auto-uplink (auto MDI/MDI-X), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility |
| Form Factor: | External |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Height: | 11 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 1 x 1000Base-T - RJ-45 ¦ 2 x aerial ¦ 1 x console - USB-C |
| Internet of Things (IoT) Compatible: | Yes |
| Line Coding Format: | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 55 °C |
| Min Operating Temperature: | -40 °C |
| OS Required: | ArubaOS, InstantOS 8.8.0.0 |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps |
| Power Consumption Operational: | 15.6 Watt |
| Power Over Ethernet (PoE) Supported: | PoE+ |
| Pricing Type: | BTO |
| Ruggedized Design: | Outdoor |
| Spread Spectrum Method: | OFDM, DSSS, OFDMA |
| Status Indicators: | System, status, radio |
| TAA Compliant: | Yes |
| Version: | original |
| Weight: | 1.03 kg |
| Width: | 16.5 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
| Warnings: | Warnings Accesspoints International.pdf |
| Safety instructions: | Safety instructions Accesspoints International.pdf |
HPE Aruba AP-565 (RW) TAA Outdoor 11ax AP (R4W53A)
| Antenna: | Internal |
|---|---|
| Capacity: | Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 ¦ OFDMA units: 16 |
| Communications Technology: | Bluetooth Low Energy (LE), Zigbee |
| Compliant Standards: | CB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU |
| Connectivity Technology: | Wireless |
| Data Link Protocol: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
| Data Transfer Rate: | 1.49 Gbps |
| Depth: | 16.5 cm |
| Device Type: | Radio access point |
| Directivity: | Omni-directional |
| Encryption Algorithm: | WPA3-Enhanced Open, WPA2-MPSK |
| Features: | Auto-uplink (auto MDI/MDI-X), Trusted Platform Module (TPM), reset button, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility |
| Form Factor: | External |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Height: | 11 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 1 x 1000Base-T - RJ-45 ¦ 2 x aerial ¦ 1 x console - USB-C |
| Internet of Things (IoT) Compatible: | Yes |
| Line Coding Format: | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA |
| Manufacturer: | HPE Aruba |
| Max Operating Temperature: | 55 °C |
| Min Operating Temperature: | -40 °C |
| OS Required: | ArubaOS, InstantOS 8.8.0.0 |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps |
| Power Consumption Operational: | 15.6 Watt |
| Power Over Ethernet (PoE) Supported: | PoE+ |
| Pricing Type: | BTO |
| Ruggedized Design: | Outdoor |
| Spread Spectrum Method: | OFDM, DSSS, OFDMA |
| Status Indicators: | System, status, radio |
| TAA Compliant: | Yes |
| Version: | original |
| Weight: | 1.03 kg |
| Width: | 16.5 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
