Cisco NCS-5501
NCS5501 Fixed 48x10G and 6x100G chassis
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
NCS5501 Fixed 48x10G and 6x100G chassis
| Authentication Method: | TACACS+ |
|---|---|
| Capacity: | FIB entries: up to 1000000 |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1ad, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1 Second Edition, RoHS 6/6, GB 4943, Directive 2004/108/EC, EN 60950-1 Second Edition, IEC 60950-1 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet |
| Depth: | 55.12 cm |
| Device Type: | Router |
| Enclosure Type: | Rack-mountable - 1U |
| Features: | Layer 3 switching, RPL support, Access Control List (ACL) support, Bidirectional Forwarding Detection (BFD), LACP support, Link Aggregation Control Protocol (LACP), Management Information Base (MIB), static routing, Class of Service (CoS), DiffServ Code P |
| Height: | 4.37 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Included Accessories: | Accessory kit |
| Installed Size: | 2 (max) |
| Interfaces: | 48 x 10Gb Ethernet - SFP/SFP+ ¦ 6 x 100Gb Ethernet - QSFP28/QSFP+ ¦ Console: 1 x RJ-45 ¦ Management: 2 x RJ-45 |
| Jumbo Frame Support: | 9216 bytes |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| OS Required: | Cisco IOS XR 6.1.1 |
| Performance: | Throughput: 800 Gbps |
| Power Device: | Internal power supply (not installed) - hot-plug |
| Power Redundancy: | Optional |
| Processor: | 1 x 2 GHz |
| Remote Management Protocol: | SNMP, SNMP 3, SSH |
| Routing Protocol: | IS-IS, BGP, HSRP, VRRP, OSPFv2, OSPFv3, ECMP, IS-ISv6, MPLS |
| Version: | original |
| Weight: | 10.34 kg |
| Width: | 44.2 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| Warnings: | Warnings Routers International.pdf |
| Safety instructions: | Safety instructions Routers International.pdf |
