Cisco C2951-UCSE/K9
Cisco 2951, SRE 900, SRE-V
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Cisco 2951, SRE 900, SRE-V
| Compliant Standards: | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 609 |
|---|---|
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Depth: | 47 cm |
| Device Type: | Router - with Cisco Services Ready Engine 900 Service Module |
| Enclosure Type: | Desktop, rack-mountable - modular - 2U |
| Expansion Slots: | 4 (total) / 4 (free) x EHWIC ¦ 3 (total) / 3 (free) x PVDM ¦ 2 (total) / 0 (free) x CompactFlash ¦ 1 (total) / 1 (free) x ISM ¦ 2 (total) / 1 (free) x service module (SM) |
| Features: | Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Web Services Management Agent (WSMA), NetFlow |
| Flash Memory: | 2.7 GB |
| Hard Drive: | 1 TB |
| Height: | 8.9 cm |
| Humidity Range Operating: | 5 - 85% |
| Interfaces: | 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ Management: 1 x console - mini-USB Type B ¦ Serial: 1 x auxiliary - RJ-45 ¦ USB: 2 x 4 pin USB Type A ¦ 1 x SFP (mini-GBIC) |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | IPSec, L2TPv3 |
| OS Provided: | Cisco IOS Universal |
| Power Device: | Internal power supply |
| Processor: | 1 x Intel Core 2 Duo 1.86 GHz |
| RAM: | 8 GB |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | SNMP, RMON, TR-069 |
| Routing Protocol: | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
| Status Indicators: | Power, link/activity |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Width: | 43.8 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| Warnings: | Warnings Routers International.pdf |
| Safety instructions: | Safety instructions Routers International.pdf |
Cisco 2951, SRE 900, SRE-V
| Compliant Standards: | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 609 |
|---|---|
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Depth: | 47 cm |
| Device Type: | Router - with Cisco Services Ready Engine 900 Service Module |
| Enclosure Type: | Desktop, rack-mountable - modular - 2U |
| Expansion Slots: | 4 (total) / 4 (free) x EHWIC ¦ 3 (total) / 3 (free) x PVDM ¦ 2 (total) / 0 (free) x CompactFlash ¦ 1 (total) / 1 (free) x ISM ¦ 2 (total) / 1 (free) x service module (SM) |
| Features: | Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Web Services Management Agent (WSMA), NetFlow |
| Flash Memory: | 2.7 GB |
| Hard Drive: | 1 TB |
| Height: | 8.9 cm |
| Humidity Range Operating: | 5 - 85% |
| Interfaces: | 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Management: 1 x console - RJ-45 ¦ Management: 1 x console - mini-USB Type B ¦ Serial: 1 x auxiliary - RJ-45 ¦ USB: 2 x 4 pin USB Type A ¦ 1 x SFP (mini-GBIC) |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | IPSec, L2TPv3 |
| OS Provided: | Cisco IOS Universal |
| Power Device: | Internal power supply |
| Processor: | 1 x Intel Core 2 Duo 1.86 GHz |
| RAM: | 8 GB |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | SNMP, RMON, TR-069 |
| Routing Protocol: | OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), IPv4-to-IPv6 Multicast |
| Status Indicators: | Power, link/activity |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Width: | 43.8 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center @ cisco.com |
