Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Capacity: | Virtual interfaces (VLANs): 1023 |
| Compliant Standards: | GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 23.8 cm |
| Device Type: | Switch - 12 ports - Managed |
| Enclosure Type: | Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
| Features: | BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), fanless, |
| Flash Memory: | 128 MB |
| Height: | 4.44 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Interfaces: | 12 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 2 x 1000Base-T RJ-45 uplink ¦ 2 x SFP uplink |
| Jumbo Frame Support: | 9018 bytes |
| MTBF: | 553,140 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | -5 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance: 16 Gbps ¦ Forwarding performance (64-byte packet size): 23.8 Mpps |
| PoE Budget: | 240 W |
| Ports: | 12 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
| Power Consumption Operational: | 23.5 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| Power Provided: | 300 Watt |
| RAM: | 512 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Routing Protocol: | RIP-1, RIP-2, static IP routing |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port status, port transmission speed, port duplex mode, system, link/activity |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 2.31 kg |
| Width: | 26.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
| Capacity: | Virtual interfaces (VLANs): 1023 |
| Compliant Standards: | GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 23.8 cm |
| Device Type: | Switch - 12 ports - Managed |
| Enclosure Type: | Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
| Features: | BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), fanless, |
| Flash Memory: | 128 MB |
| Height: | 4.44 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Interfaces: | 12 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 2 x 1000Base-T RJ-45 uplink ¦ 2 x SFP uplink |
| Jumbo Frame Support: | 9018 bytes |
| MTBF: | 553,140 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | -5 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance: 16 Gbps ¦ Forwarding performance (64-byte packet size): 23.8 Mpps |
| PoE Budget: | 240 W |
| Ports: | 12 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
| Power Consumption Operational: | 23.5 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| Power Provided: | 300 Watt |
| RAM: | 512 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| Routing Protocol: | RIP-1, RIP-2, static IP routing |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port status, port transmission speed, port duplex mode, system, link/activity |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 2.31 kg |
| Width: | 26.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
