Juniper QFX5100-48T-AFO
QFX5100, 48 100M/1G/10G Base-T, 6 QSFP ports, redundant fans, redundant power supplies, Built in Port to PSU air flow.
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
QFX5100, 48 100M/1G/10G Base-T, 6 QSFP ports, redundant fans, redundant power supplies, Built in Port to PSU air flow.
| 80 PLUS Certification: | 80 PLUS |
|---|---|
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Built-in Devices: | 32 GB SSD |
| Capacity: | IPv4 routes (Unicast): 128000 ¦ Virtual interfaces (VLANs): 4091 ¦ IPv4 hosts: 208000 ¦ IPv4 routes (Multicast): 104000 ¦ IPv6 routes (Multicast): 52000 ¦ IPv6 routes (Unicast): 64000 ¦ ARP entries: 48000 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ |
| Compliant Standards: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, Shaped Deficit Weighted Round-Robin (SDWRR), NEBS level 3, EN55022 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, BSMI CNS 13438, REACH, EN 60825-1, GR-1089-CORE, VCCI Class A, GR-63-CORE, NCC, China RoHS, AS/NZS CISPR 22, CAN/CSA-C22.2 No. 60950-1 |
| Depth: | 54.54 cm |
| Device Type: | Switch - 48 ports - L3 - Managed |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, AES |
| Features: | Flow control, VPN support, BOOTP support, RARP support, ARP support, trunking, VLAN support, IGMP snooping, DoS attack prevention, store and forward, MAC address filtering, IPv6 support, High Availability, SNTP support, Low-latency queuing (LLQ), Weighted |
| Fibre Channel: | FC-BB-5, FC-BB-6 |
| Height: | 4.37 cm |
| Humidity Range Operating: | 5 - 90% (non-condensing) |
| Humidity Range Storage: | 0 - 95% (non-condensing) |
| Installed Qty: | 2 |
| Interfaces: | 48 x 10GBase-T RJ-45 ¦ 6 x QSFP+ (breakout compatible) ¦ 1 x console management ¦ 1 x USB management ¦ 1 x RJ-45 management ¦ 1 x SFP management |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 288K entries |
| Manufacturer: | Juniper HPE |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| OS Required: | JUNOS |
| Performance: | Switching capacity: 1.44 Tbps ¦ Switching capacity: 1.08 Bpps |
| Ports: | 48 x 100/1000/10000 + 6 x 40 Gigabit QSFP+ (breakout compatible) |
| Power Consumption Operational: | 335 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Processor: | 1 x Intel: 1.5 GHz |
| RAM: | 8 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH, CLI |
| Routing Protocol: | OSPF, RIP, RIP-2, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, IGMPv3, MSDP, ECMP, Bidirectional Forwarding Detection (BFD), CIDR |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V |
| Weight: | 11.2 kg |
| Width: | 44.09 cm |
| GPSR - economic actor: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
|---|---|
| GPSR - product manufacturer: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| GPSR - EU responsible person: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| EU Data-Act-Url: | https://www.juniper.net/us/en/privacy-policy/european-privacy-policy.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
QFX5100, 48 100M/1G/10G Base-T, 6 QSFP ports, redundant fans, redundant power supplies, Built in Port to PSU air flow.
| 80 PLUS Certification: | 80 PLUS |
|---|---|
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Built-in Devices: | 32 GB SSD |
| Capacity: | IPv4 routes (Unicast): 128000 ¦ Virtual interfaces (VLANs): 4091 ¦ IPv4 hosts: 208000 ¦ IPv4 routes (Multicast): 104000 ¦ IPv6 routes (Multicast): 52000 ¦ IPv6 routes (Unicast): 64000 ¦ ARP entries: 48000 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ |
| Compliant Standards: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, Shaped Deficit Weighted Round-Robin (SDWRR), NEBS level 3, EN55022 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, BSMI CNS 13438, REACH, EN 60825-1, GR-1089-CORE, VCCI Class A, GR-63-CORE, NCC, China RoHS, AS/NZS CISPR 22, CAN/CSA-C22.2 No. 60950-1 |
| Depth: | 54.54 cm |
| Device Type: | Switch - 48 ports - L3 - Managed |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, AES |
| Features: | Flow control, VPN support, BOOTP support, RARP support, ARP support, trunking, VLAN support, IGMP snooping, DoS attack prevention, store and forward, MAC address filtering, IPv6 support, High Availability, SNTP support, Low-latency queuing (LLQ), Weighted |
| Fibre Channel: | FC-BB-5, FC-BB-6 |
| Height: | 4.37 cm |
| Humidity Range Operating: | 5 - 90% (non-condensing) |
| Humidity Range Storage: | 0 - 95% (non-condensing) |
| Installed Qty: | 2 |
| Interfaces: | 48 x 10GBase-T RJ-45 ¦ 6 x QSFP+ (breakout compatible) ¦ 1 x console management ¦ 1 x USB management ¦ 1 x RJ-45 management ¦ 1 x SFP management |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 288K entries |
| Manufacturer: | Juniper HPE |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| OS Required: | JUNOS |
| Performance: | Switching capacity: 1.44 Tbps ¦ Switching capacity: 1.08 Bpps |
| Ports: | 48 x 100/1000/10000 + 6 x 40 Gigabit QSFP+ (breakout compatible) |
| Power Consumption Operational: | 335 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Processor: | 1 x Intel: 1.5 GHz |
| RAM: | 8 GB |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH, CLI |
| Routing Protocol: | OSPF, RIP, RIP-2, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, IGMPv3, MSDP, ECMP, Bidirectional Forwarding Detection (BFD), CIDR |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V |
| Weight: | 11.2 kg |
| Width: | 44.09 cm |
| GPSR - economic actor: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
|---|---|
| GPSR - product manufacturer: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| GPSR - EU responsible person: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info@juniper.net |
| EU Data-Act-Url: | https://www.juniper.net/us/en/privacy-policy/european-privacy-policy.html |
