Aruba R9W93A
Aruba 8100 40XT8XF4C 3 Fans, 2 AC Power Supplies R9W93A (Back to Front)
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Aruba 8100 40XT8XF4C 3 Fans, 2 AC Power Supplies R9W93A (Back to Front)
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Capacity: | IPv4 ACL entries (ingress): 16384 ¦ IPv6 ACL entries (ingress): 4096 ¦ MAC ACL entries (ingress): 16384 ¦ IPv4 ACL entries (egress): 2048 ¦ IPv6 ACL entries (egress): 512 ¦ MAC ACL entries (egress): 2048 ¦ Maximum number of VLANs: 1024 ¦ IGMP groups: 4000 |
| Compliant Standards: | IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, Laser Class 1, EN 61000-4-8, VCCI Class A, EN, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3an, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.3by |
| Depth: | 40.64 cm |
| Device Type: | Switch - 40 ports - L3 - Managed |
| Enclosure Type: | Back to front airflow rack-mountable 1U |
| Features: | Layer 2 switching, port mirroring, sFlow, Quality of Service (QoS), Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), Data Center Bridging (DCB), Generic Routing Encapsulation (GRE), Ethernet Ring Protection Switching (ERPS), RDMA ove |
| Flash Memory: | 32 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 95% (non-condensing) |
| Included Accessories: | 3 fan trays, 2-Post Rack Kit |
| Installed Qty: | 2 |
| Interfaces: | 40 x 100/1000/2.5G/5G/10GBase-T RJ-45 ¦ 8 x Gigabit / 10Gbit LANSFP+ ¦ 4 x 40/100Gbit LAN QSFP28/QSFP+ ¦ 1 x USB-C console ¦ 1 x serial RJ-45 ¦ 1 x USB Type A AUX |
| Jumbo Frame Support: | 9000 bytes |
| MAC Address Table Size: | 147456 entries |
| Manufacturer: | Aruba HPE |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| OS Required: | AOS-CX |
| Performance: | Switching capacity: 1.76 Tbps |
| Ports: | 40 x 100/1000/2.5G/5G/10GBase-T + 8 x Gigabit SFP / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28 |
| Power Consumption Stand by: | 120 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Provided: | 550 Watt |
| Processor: | 1 x ARM Cortex-A72: 1.8 GHz |
| RAM: | 16 GB |
| Remote Management Protocol: | SNMP 2, SNMP, SNMP 3, MIB |
| Routing Protocol: | BGP-4, RIP-2, IGMPv2, IGMP, IGMPv3, MLDv2, MLD |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 100-127/200-240 V (50/60 Hz) |
| Weight: | 8.57 kg |
| Width: | 44.25 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
Aruba 8100 40XT8XF4C 3 Fans, 2 AC Power Supplies R9W93A (Back to Front)
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Capacity: | IPv4 ACL entries (ingress): 16384 ¦ IPv6 ACL entries (ingress): 4096 ¦ MAC ACL entries (ingress): 16384 ¦ IPv4 ACL entries (egress): 2048 ¦ IPv6 ACL entries (egress): 512 ¦ MAC ACL entries (egress): 2048 ¦ Maximum number of VLANs: 1024 ¦ IGMP groups: 4000 |
| Compliant Standards: | IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, Laser Class 1, EN 61000-4-8, VCCI Class A, EN, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3an, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.3by |
| Depth: | 40.64 cm |
| Device Type: | Switch - 40 ports - L3 - Managed |
| Enclosure Type: | Back to front airflow rack-mountable 1U |
| Features: | Layer 2 switching, port mirroring, sFlow, Quality of Service (QoS), Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), Data Center Bridging (DCB), Generic Routing Encapsulation (GRE), Ethernet Ring Protection Switching (ERPS), RDMA ove |
| Flash Memory: | 32 GB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 15 - 95% (non-condensing) |
| Humidity Range Storage: | 15 - 95% (non-condensing) |
| Included Accessories: | 3 fan trays, 2-Post Rack Kit |
| Installed Qty: | 2 |
| Interfaces: | 40 x 100/1000/2.5G/5G/10GBase-T RJ-45 ¦ 8 x Gigabit / 10Gbit LANSFP+ ¦ 4 x 40/100Gbit LAN QSFP28/QSFP+ ¦ 1 x USB-C console ¦ 1 x serial RJ-45 ¦ 1 x USB Type A AUX |
| Jumbo Frame Support: | 9000 bytes |
| MAC Address Table Size: | 147456 entries |
| Manufacturer: | Aruba HPE |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| OS Required: | AOS-CX |
| Performance: | Switching capacity: 1.76 Tbps |
| Ports: | 40 x 100/1000/2.5G/5G/10GBase-T + 8 x Gigabit SFP / 10 Gigabit SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28 |
| Power Consumption Stand by: | 120 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Provided: | 550 Watt |
| Processor: | 1 x ARM Cortex-A72: 1.8 GHz |
| RAM: | 16 GB |
| Remote Management Protocol: | SNMP 2, SNMP, SNMP 3, MIB |
| Routing Protocol: | BGP-4, RIP-2, IGMPv2, IGMP, IGMPv3, MLDv2, MLD |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 100-127/200-240 V (50/60 Hz) |
| Weight: | 8.57 kg |
| Width: | 44.25 cm |
| GPSR - economic actor: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
|---|---|
| GPSR - product manufacturer: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| GPSR - EU responsible person: | Hewlett-Packard GmbH, Deutschland, Herrenberger Str. 140, Böblingen, 71034, enterprise.kunden@hpe.com |
| EU Data-Act-Url: | https://www.hpe.com/us/en/living-progress/governance/policies.html |
