Juniper QFX5200-32C-AFI
QFX5200, 32 QSF+ ports, redundant fans, 2 AC power supplies, back to front airflow, SW license not included.
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
QFX5200, 32 QSF+ ports, redundant fans, 2 AC power supplies, back to front airflow, SW license not included.
| 80 PLUS Certification: | 80 PLUS Silver |
|---|---|
| Built-in Devices: | 64 GB SSD |
| Compliant Standards: | ETSI, CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, REACH, EN 60825-1, ETS 300 753, VCCI Class A, KN22 Class A, China RoHS, ETSI 300 019, EN 5502 |
| Depth: | 52.02 cm |
| Device Type: | Switch - 32 ports - Managed |
| Enclosure Type: | Back to front airflow rack-mountable 1U |
| Features: | Redundant hot swappable fans, 16MB packet buffer |
| Height: | 4.37 cm |
| Humidity Range Operating: | 5 - 90% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Installed Qty: | 2 |
| Interfaces: | 32 x 100Gbit/40Gbit LAN QSFP28/QSFP+ (breakout compatible) ¦ 1 x console management ¦ 1 x USB 2.0 management ¦ 2 x 1000Base-T RJ-45 management ¦ 2 x SFP management |
| Manufacturer: | Juniper HPE |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| OS Required: | JUNOS |
| Performance: | Throughput: 3.2 Tbps ¦ Switching capacity: 2.4 Bpps |
| Ports: | 32 x 100 Gigabit QSFP28 / 40 Gigabit QSFP+ (breakout compatible) |
| Power Consumption Operational: | 480 Watt |
| Power Device: | Internal power supply - hot-plug |
| Power Provided: | 850 Watt |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Processor: | 1 x Intel: 1.8 GHz |
| RAM: | 16 GB SDRAM |
| Subtype: | 100 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V |
| Weight: | 10.8 kg |
| Width: | 44.09 cm |
| GPSR - economic actor: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info @ juniper.net |
|---|---|
| GPSR - product manufacturer: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info @ juniper.net |
| GPSR - EU responsible person: | Juniper Networks GmbH, Deutschland, Oskar-Schlemmer-Str. 15, München, 80807, info @ juniper.net |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
