Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| Cabling Type: | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
|---|---|
| Compliant Standards: | IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP) |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Depth: | 14 cm |
| Designed For: | IBM System x3650 1914 ¦ Lenovo System x3100 M4 2582 ¦ Lenovo System x3100 M5 ¦ Lenovo System x3200 M2 4367, 4368 ¦ Lenovo System x3200 M3 7327, 7328 ¦ Lenovo System x3250 M2 4190, 4194 ¦ Lenovo System x3250 M3 4251, 4252 ¦ Lenovo System x3250 M4 ¦ Lenovo |
| Device Type: | Network adapter |
| Features: | VLAN support, TCP/IP offloading, Intel I/O Acceleration Technology (I/OAT), Jumbo Frames support, Virtual Machine Device Queues (VMDq), PXE support, Receive Side Scaling (RSS) |
| Form Factor: | Plug-in card - low profile |
| Height: | 7 cm |
| Humidity Range Operating: | 20 - 80% (non-condensing) |
| Interface (Bus) Type: | PCI Express 2.0 x4 |
| Interfaces: | 2 x 1000Base-T - RJ-45 |
| Manufacturer: | IBM |
| Max Operating Temperature: | 35 °C |
| Min Operating Temperature: | 10 °C |
| Network / Transport Protocol: | TCP/IP |
| OS Required: | SuSE Linux Enterprise Server 11, VMware ESXi 4.0, SuSE Linux Enterprise Server 10, Microsoft Windows 2003, Red Hat Enterprise Linux 5, Microsoft Windows Server 2008, Red Hat Enterprise Linux 6, VMware ESX 4.1, VMware ESX 4.0, VMware ESXi 4.1, VMware ESXi |
| PCI Specification Revision: | PCIe 2.0 |
| Ports: | Gigabit Ethernet x 2 |
| Pricing Type: | Customer Replaceable Unit (CRU) - Tier 1 |
| Version: | original |
| Weight: | 250 g |
| Width: | 1.6 cm |
| GPSR - economic actor: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
|---|---|
| GPSR - product manufacturer: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
| GPSR - EU responsible person: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
| Warnings: | Warnings Adapter PCI International.pdf |
| Safety instructions: | Safety instructions Adapter PCI International.pdf |
| Cabling Type: | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
|---|---|
| Compliant Standards: | IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP) |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Depth: | 14 cm |
| Designed For: | IBM System x3650 1914 ¦ Lenovo System x3100 M4 2582 ¦ Lenovo System x3100 M5 ¦ Lenovo System x3200 M2 4367, 4368 ¦ Lenovo System x3200 M3 7327, 7328 ¦ Lenovo System x3250 M2 4190, 4194 ¦ Lenovo System x3250 M3 4251, 4252 ¦ Lenovo System x3250 M4 ¦ Lenovo |
| Device Type: | Network adapter |
| Features: | VLAN support, TCP/IP offloading, Intel I/O Acceleration Technology (I/OAT), Jumbo Frames support, Virtual Machine Device Queues (VMDq), PXE support, Receive Side Scaling (RSS) |
| Form Factor: | Plug-in card - low profile |
| Height: | 7 cm |
| Humidity Range Operating: | 20 - 80% (non-condensing) |
| Interface (Bus) Type: | PCI Express 2.0 x4 |
| Interfaces: | 2 x 1000Base-T - RJ-45 |
| Manufacturer: | IBM |
| Max Operating Temperature: | 35 °C |
| Min Operating Temperature: | 10 °C |
| Network / Transport Protocol: | TCP/IP |
| OS Required: | SuSE Linux Enterprise Server 11, VMware ESXi 4.0, SuSE Linux Enterprise Server 10, Microsoft Windows 2003, Red Hat Enterprise Linux 5, Microsoft Windows Server 2008, Red Hat Enterprise Linux 6, VMware ESX 4.1, VMware ESX 4.0, VMware ESXi 4.1, VMware ESXi |
| PCI Specification Revision: | PCIe 2.0 |
| Ports: | Gigabit Ethernet x 2 |
| Pricing Type: | Customer Replaceable Unit (CRU) - Tier 1 |
| Version: | original |
| Weight: | 250 g |
| Width: | 1.6 cm |
| GPSR - economic actor: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
|---|---|
| GPSR - product manufacturer: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
| GPSR - EU responsible person: | IBM, Deutschland, Schönaicher Str. 220, Böblingen, 71032, halloibm@de.ibm.com |
