| Authentication Method: | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Compliant Standards: | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, NEBS level 3, CISPR 22 Class A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, VCCI Class A ITE, EN55024, EN5502 |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Depth: | 32.1 cm |
| Device Type: | Router |
| Enclosure Type: | Rack-mountable - 1U |
| Features: | IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Equal-Cost Multipath (ECMP), LLDP support, DHCP c |
| Flash Memory: | 128 MB |
| Height: | 4.32 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Installed Qty: | 2 (installed) / 2 (max) |
| Interfaces: | 4 x 1000Base-T - RJ-45 ¦ 4 x 100Base-TX/1000Base-T - RJ-45 ¦ 8 x SFP (mini-GBIC) ¦ 2 x 10Gb Ethernet - SFP+ ¦ Serial: 1 x console - RJ-45 ¦ USB: 1 x ¦ Management: 1 x RJ-45 ¦ 2 x RJ-45 |
| MTBF: | 491,160 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 65 °C |
| Min Operating Temperature: | -40 °C |
| Power Consumption Operational: | 58 Watt |
| Power Device: | Internal power supply |
| Power Redundancy: | Yes |
| RAM: | 512 MB DDR3 SDRAM |
| Remote Management Protocol: | SNMP, Telnet, CLI |
| Routing Protocol: | OSPF, IS-IS, BGP, static IP routing, ECMP, MPLS, Bidirectional Forwarding Detection (BFD) |
| Version: | original |
| Voltage Required: | DC -24/-60 V |
| Weight: | 3.6 kg |
| Width: | 44.45 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Routers International.pdf |
| Safety instructions: | Safety instructions Routers International.pdf |
