| Authentication Method: | Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Compliant Standards: | FCC Class A certified, TUV GS, GOST, BSMI CNS 13438 Class A, CISPR 24, cUL, NOM, VCCI Class A ITE, EN55024, EN55022 Class A, CISPR 22, CSA 22.2 No. 60950, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, EMC, FCC Part 15, MIC, UL 60950-1, IEC 60950-1, EN 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Depth: | 37.8 cm |
| Device Type: | Switch - 24 ports - L3 - Managed |
| Enclosure Type: | Desktop 1U |
| Features: | Full duplex capability, Layer 3 switching, Layer 2 switching, auto-sensing per device, IP-routing, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, trunking, MPLS support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, t |
| Features: | Redundant Power System (RPS) connector |
| Flash Memory: | 32 MB Flash |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE ¦ 1 x console RJ-45 management ¦ 4 x SFP (mini-GBIC) |
| MAC Address Table Size: | 12K entries |
| MTBF: | 186,300 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance (64-byte packet size): 38.7 Mpps |
| Ports: | 24 x 10/100/1000 (PoE) + 4 x Gigabit SFP |
| Power Consumption Operational: | 540 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE |
| RAM: | 128 MB |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH-2 |
| Routing Protocol: | RIP-1, RIP-2, HSRP, static IP routing, RIPng |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port transmission speed, port duplex mode, system, RPS (Redundant Power Supply), PoE, link/activity |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 6.1 kg |
| Width: | 44.5 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| Authentication Method: | Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Compliant Standards: | FCC Class A certified, TUV GS, GOST, BSMI CNS 13438 Class A, CISPR 24, cUL, NOM, VCCI Class A ITE, EN55024, EN55022 Class A, CISPR 22, CSA 22.2 No. 60950, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, EMC, FCC Part 15, MIC, UL 60950-1, IEC 60950-1, EN 60950-1, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Depth: | 37.8 cm |
| Device Type: | Switch - 24 ports - L3 - Managed |
| Enclosure Type: | Desktop 1U |
| Features: | Full duplex capability, Layer 3 switching, Layer 2 switching, auto-sensing per device, IP-routing, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, trunking, MPLS support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, t |
| Features: | Redundant Power System (RPS) connector |
| Flash Memory: | 32 MB Flash |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE ¦ 1 x console RJ-45 management ¦ 4 x SFP (mini-GBIC) |
| MAC Address Table Size: | 12K entries |
| MTBF: | 186,300 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -25 °C |
| Performance: | Forwarding performance (64-byte packet size): 38.7 Mpps |
| Ports: | 24 x 10/100/1000 (PoE) + 4 x Gigabit SFP |
| Power Consumption Operational: | 540 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE |
| RAM: | 128 MB |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH-2 |
| Routing Protocol: | RIP-1, RIP-2, HSRP, static IP routing, RIPng |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port transmission speed, port duplex mode, system, RPS (Redundant Power Supply), PoE, link/activity |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 6.1 kg |
| Width: | 44.5 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
