| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+ |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 512 ¦ ARP entries: 1024 ¦ NDP entries: 400 ¦ Priority queues per port: 8 ¦ IPv4 routes (static): 256 ¦ IPv6 routes (static): 128 ¦ IPv4 routes (dynamic): 256 ¦ VLAN routing interfaces: 128 ¦ ACL: 100 ¦ Max ACL rules system-wide |
| Compliant Standards: | FCC Class A certified, cUL, GS, RoHS, WEEE, REACH, ICES Class A, VCCI Class A, EAC, CCC Class A, IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 38.7 cm |
| Device Type: | Switch - 24 ports - L2+ - Managed - stackable |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, AES, SSL, TLS |
| Features: | Auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, DiffServ support, Broadcast Storm Control, IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), P |
| Flash Memory: | 256 MB |
| Height: | 4.32 cm |
| Humidity Range Operating: | 95% |
| Humidity Range Storage: | 85% |
| Installed Qty: | 1 |
| Interfaces: | 24 x Gigabit LAN RJ-45 PoE+ ¦ 4 x 10Gbit LANSFP+ ¦ 1 x serial (RS-232) RJ-45 management ¦ 1 x USB Type A ¦ 2 x network stack device |
| MAC Address Table Size: | 16000 entries |
| Manufacturer: | Dell |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 65 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching fabric bandwidth: 128 Gbps ¦ Forwarding performance: 128 Mpps |
| PoE Budget: | 30.8 W |
| Ports: | 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| RAM: | 1 GB |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, TFTP |
| Routing Protocol: | RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 100-240 V |
| Weight: | 5.8 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
|---|---|
| GPSR - product manufacturer: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
| GPSR - EU responsible person: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
| EU Data-Act-Url: | https://www.dell.com/en-us/lp/legal/eu-data-act-aup |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
| Authentication Method: | Secure Shell (SSH), RADIUS, TACACS+ |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 512 ¦ ARP entries: 1024 ¦ NDP entries: 400 ¦ Priority queues per port: 8 ¦ IPv4 routes (static): 256 ¦ IPv6 routes (static): 128 ¦ IPv4 routes (dynamic): 256 ¦ VLAN routing interfaces: 128 ¦ ACL: 100 ¦ Max ACL rules system-wide |
| Compliant Standards: | FCC Class A certified, cUL, GS, RoHS, WEEE, REACH, ICES Class A, VCCI Class A, EAC, CCC Class A, IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az |
| Depth: | 38.7 cm |
| Device Type: | Switch - 24 ports - L2+ - Managed - stackable |
| Enclosure Type: | Front to back airflow rack-mountable 1U |
| Encryption Algorithm: | MD5, AES, SSL, TLS |
| Features: | Auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, DiffServ support, Broadcast Storm Control, IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), P |
| Flash Memory: | 256 MB |
| Height: | 4.32 cm |
| Humidity Range Operating: | 95% |
| Humidity Range Storage: | 85% |
| Installed Qty: | 1 |
| Interfaces: | 24 x Gigabit LAN RJ-45 PoE+ ¦ 4 x 10Gbit LANSFP+ ¦ 1 x serial (RS-232) RJ-45 management ¦ 1 x USB Type A ¦ 2 x network stack device |
| MAC Address Table Size: | 16000 entries |
| Manufacturer: | Dell |
| Max Operating Temperature: | 45 °C |
| Max Storage Temperature: | 65 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching fabric bandwidth: 128 Gbps ¦ Forwarding performance: 128 Mpps |
| PoE Budget: | 30.8 W |
| Ports: | 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| RAM: | 1 GB |
| Rack Mounting Kit: | Included |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, TFTP |
| Routing Protocol: | RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 100-240 V |
| Weight: | 5.8 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
|---|---|
| GPSR - product manufacturer: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
| GPSR - EU responsible person: | Dell GmbH, Deutschland, Main Airport Center Unterschweinstiege 10, Frankfurt am Main, 60549, DE.CustomerSupport@dell.com |
| EU Data-Act-Url: | https://www.dell.com/en-us/lp/legal/eu-data-act-aup |
