Layer 2/3 FortiGate switch controller compatible PoE+ switch with 48 x GE RJ45 ports, 4 x GE SFP, with automatic Max 370W POE output limit
| Authentication Method: | RADIUS |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 4000 ¦ Link aggregation groups: 26 ¦ Link aggregation groups: 8 ¦ MSTP instances: 15 ¦ Routing entries: 64 ¦ Host entries: 4000 ¦ ACL entries: 512 |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.1AX, UL, VCCI, BSMI, CB, FCC, RoHS2, RCM |
| Depth: | 41 cm |
| Device Type: | Switch - 52 ports - L3 - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Features: | Flow control, auto-negotiation, IGMP snooping, port mirroring, SNTP support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Jumbo Frames support, Dyn |
| Flash Memory: | 128 MB |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 90% |
| Interfaces: | 24 x 1000Base-T RJ-45 PoE+ ¦ 24 x 1000Base-T RJ-45 ¦ 4 x Gigabit LANSFP ¦ 1 x console RJ-45 ¦ 1 x management RJ-45 |
| Jumbo Frame Support: | Yes |
| MAC Address Table Size: | 16000 entries |
| Manufacturer: | Fortinet |
| Max Operating Temperature: | 50 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -20 °C |
| Performance: | Switching capacity: 104 Gbps ¦ Packet transfer capability: 155 Mpps ¦ Latency: 1 µs |
| PoE Budget: | 370 W |
| Ports: | 24 x 10/100/1000 (PoE+) + 24 x 10/100/1000 + 4 x Gigabit SFP |
| Power Consumption Operational: | 51.6 Watt |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE+ |
| RAM: | 512 MB |
| Remote Management Protocol: | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI |
| Routing Protocol: | RIP-2, VRRP, OSPFv2 |
| Subtype: | Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50 - 60 Hz) |
| Weight: | 5.5 kg |
| Width: | 44 cm |
| GPSR - economic actor: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
|---|---|
| GPSR - product manufacturer: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| GPSR - EU responsible person: | Fortinet, Deutschland, Weihenstephaner Str. 12, München, 81673, cs@fortinet.com |
| EU Data-Act-Url: | https://www.fortinet.com/de/corporate/about-us/gdpr |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
