| Cabling Type: | Ethernet 1000Base-X |
|---|---|
| Compatible Slots: | 1 x Expansion Slot |
| Compliant Standards: | NEBS level 3, CISPR 22 Class A, VCCI Class B ITE, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 6 |
| Compliant Standards: | IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ad |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Gigabit Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Depth: | 18.5 cm |
| Designed For: | Cisco 12004, 12006, 12008, 12010, 12012, 12016, 12404, 12406, 12410, 12416, 12810, 12816, 7603, 7604, 7604 Security Bundle, 7606, 7606 Security Bundle, 7606-S, 7609, 7609 Security Bundle, 7613, 7613 Security Bundle ¦ Cisco Carrier Routing System CRS-1 ¦ C |
| Device Type: | Expansion module - 5 ports |
| Expansion Slots: | 5 (total) / 5 (free) x SFP |
| Features: | Flow control, full duplex capability, auto-negotiation, MPLS support, VLAN support, MAC address filtering, Quality of Service (QoS), Jumbo Frames support |
| Form Factor: | Plug-in module |
| Height: | 2 cm |
| Humidity Range Operating: | 5 - 85% |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Remote Management Protocol: | SNMP, RMON, CLI |
| Status Indicators: | Port status, power, status |
| Version: | original |
| Weight: | 340 g |
| Width: | 17.2 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Adapter Gigabit International.pdf |
| Safety instructions: | Safety instructions Adapter Gigabit International.pdf |
| Cabling Type: | Ethernet 1000Base-X |
|---|---|
| Compatible Slots: | 1 x Expansion Slot |
| Compliant Standards: | NEBS level 3, CISPR 22 Class A, VCCI Class B ITE, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 6 |
| Compliant Standards: | IEEE 802.3z, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1ad |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Gigabit Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Depth: | 18.5 cm |
| Designed For: | Cisco 12004, 12006, 12008, 12010, 12012, 12016, 12404, 12406, 12410, 12416, 12810, 12816, 7603, 7604, 7604 Security Bundle, 7606, 7606 Security Bundle, 7606-S, 7609, 7609 Security Bundle, 7613, 7613 Security Bundle ¦ Cisco Carrier Routing System CRS-1 ¦ C |
| Device Type: | Expansion module - 5 ports |
| Expansion Slots: | 5 (total) / 5 (free) x SFP |
| Features: | Flow control, full duplex capability, auto-negotiation, MPLS support, VLAN support, MAC address filtering, Quality of Service (QoS), Jumbo Frames support |
| Form Factor: | Plug-in module |
| Height: | 2 cm |
| Humidity Range Operating: | 5 - 85% |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Remote Management Protocol: | SNMP, RMON, CLI |
| Status Indicators: | Port status, power, status |
| Version: | original |
| Weight: | 340 g |
| Width: | 17.2 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
