Cisco FPR1150-NGFW-K9
Cisco Firepower 1150 NGFW Appliance, 1U
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Cisco Firepower 1150 NGFW Appliance, 1U
| Airflow Direction: | Front to back airflow |
|---|---|
| Capacity: | Maximum concurrent sessions with AVC: 600000 ¦ New connections per second with AVC: 28000 ¦ VPN peers: 800 ¦ Concurrent firewall connections: 600000 ¦ New connections per second: 150000 |
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2 |
| Connectivity Technology: | Wired |
| Depth: | 26.87 cm |
| Device Type: | Firewall |
| Features: | 1 fan |
| Form Factor: | Rack-mountable |
| Hard Drive: | SSD 200 GB x 1 |
| Height: | 4.37 cm |
| Height (Rack Units): | 1U |
| Humidity Range Operating: | 90% (non-condensing) |
| Included Accessories: | Mounting brackets |
| Installed Qty: | 1 |
| Interfaces: | 8 x 1000Base-T - RJ-45 ¦ 2 x 1000Base-X - SFP+ ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x serial - RJ-45 ¦ 1 x USB 3.0 - Type A ¦ 2 x 10GBase-X - SFP (mini-GBIC) |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Max Supported Qty: | 1 |
| Min Operating Temperature: | 0 °C |
| Performance: | Firewall and Application Visibility and Control (AVC) throughput (1024B): 3 Gbps ¦ Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (1024B): 3 Gbps ¦ Transport Layer Security (TLS) throughput: 1.4 Gbps |
| Power Device: | Internal power supply |
| Power Provided: | 100 Watt |
| Processors Installed: | 1 x Intel |
| RAM: | 32 GB DDR4 SDRAM |
| Software Included: | Cisco Threat Defense 6.5 |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 3.63 kg |
| Width: | 43.69 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Firewalls International.pdf |
| Safety instructions: | Safety instructions Firewalls International.pdf |
