| Authentication Method: | Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
|---|---|
| Compliant Standards: | FCC Class A certified, UL, TUV GS, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CB, AS/NZ 3548 Class A, FCC Part 15, CSA C22.2 No. 60950-00, MIC, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Depth: | 23 cm |
| Device Type: | Switch - 12 ports - L3 - Managed |
| Enclosure Type: | Desktop 1U |
| Features: | Auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast |
| Flash Memory: | 32 MB Flash |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% |
| Interfaces: | 12 x 100Base-TX RJ-45 PoE ¦ 1 x 1000Base-T RJ-45 ¦ 1 x console RJ-45 management ¦ 1 x SFP (mini-GBIC) |
| MAC Address Table Size: | 12K entries |
| MTBF: | 406,470 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 45 °C |
| Min Operating Temperature: | 0 °C |
| Ports: | 12 x 10/100 (PoE) + 1 x combo Gigabit SFP |
| Power Device: | Internal power supply |
| Power Over Ethernet (PoE): | PoE |
| RAM: | 128 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, FTP, TFTP, SSH-2 |
| Routing Protocol: | RIP-1, RIP-2, HSRP, static IP routing, policy-based routing (PBR), RIPng |
| Software Included: | Cisco IOS IP Base |
| Status Indicators: | Port status, port transmission speed, port duplex mode, power, system, link/activity |
| Subtype: | Fast Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 2.3 kg |
| Width: | 27 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
