Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
| Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
|---|---|
| Cables Included: | 1 x serial cable |
| Compliant Standards: | FCC Class A certified, CSA, UL, TUV GS, CISPR 24, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CISPR 22, CB, AS/NZ 3548 Class A, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Depth: | 30.1 cm |
| Device Type: | Switch - 48 ports - Managed - stackable |
| Enclosure Type: | Rack-mountable 1U |
| Features: | Redundant Power System (RPS) connector |
| Features: | Flow control, full duplex capability, routing, auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, trunking, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, manageable, stackable, IPv6 support |
| Flash Memory: | 16 MB Flash |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% |
| Installed Modules Qty (Max): | 0 (installed) / 4 (max) |
| Interfaces: | 48 x 10Base-T/100Base-TX - RJ-45 ¦ 1 x console - RJ-45 management ¦ 2 x network stack device ¦ 4 x SFP (mini-GBIC) |
| MAC Address Table Size: | 12K entries |
| MTBF: | 217,824 hours |
| Manufacturer: | Cisco Meraki |
| Max Altitude Operating: | 3 km |
| Max Operating Temperature: | 45 °C |
| Min Operating Temperature: | 0 °C |
| Ports: | 48 x 10/100 + 4 x SFP |
| Power Consumption Operational: | 75 Watt |
| Power Device: | Internal power supply |
| RAM: | 128 MB |
| Rack Mounting Kit: | Optional |
| Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, SNMP, Telnet, SNMP 3, SNMP 2c |
| Routing Protocol: | OSPF, IGRP, BGP-4, RIP-1, RIP-2, EIGRP, HSRP, IGMP, DVMRP, PIM-SM, static IP routing, PIM-DM |
| Software Included: | Enhanced Multilayer Software Image (EMI) |
| Status Indicators: | Port status, port transmission speed, port duplex mode, power, link/activity |
| Subtype: | Fast Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 4.1 kg |
| Width: | 44.5 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
