Cisco N3K-C3132Q-V
Nexus 3132 VXLAN, 32x40G QSFP+ Ports
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Nexus 3132 VXLAN, 32x40G QSFP+ Ports
| Authentication Method: | Secure Shell (SSH) |
|---|---|
| Cables Included: | 2 x power cable |
| Capacity: | Virtual interfaces (VLANs): 4096 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ Rapid Spanning Tree Protocol instances: 512 ¦ MAC addresses: 288000 ¦ ACL entries (egress): 1000 ¦ ACL entries (ingress): 16000 |
| Compliant Standards: | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, FCC CFR47, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edit, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 1588-2008 |
| Depth: | 50.5 cm |
| Device Type: | Switch - 32 ports - L3 - Managed |
| Enclosure Type: | Front and side to back rack-mountable 1U |
| Features: | DHCP support, VLAN support, Syslog support, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, EIGRP Stub Routing, Equal-Cost Mult |
| Height: | 4.4 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Installed Qty: | 2 |
| Interfaces: | 32 x 40Gbit LAN QSFP+ ¦ 4 x 10GBase-X SFP+ ¦ 1 x 1000Base-T RJ-45 management ¦ 1 x serial (RS-232) ¦ 1 x USB |
| Jumbo Frame Support: | 9216 bytes |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching capacity: 2.56 Tbps ¦ Forwarding performance: 1.4 Bpps |
| Ports: | 32 x QSFP+ |
| Power Consumption Operational: | 170 Watt |
| Power Device: | Internal power supply - hot-plug |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI |
| Routing Protocol: | RIP-2, BGP, EIGRP, VRRP, OSPFv2, PIM-SM, static IP routing, PIM-SSM, MSDP, policy-based routing (PBR) |
| Subtype: | 40 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 8.5 kg |
| Width: | 43.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
