Cisco N3K-C3524P-10GX
Nexus 3524x, 24 10G Ports
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
Nexus 3524x, 24 10G Ports
| Authentication Method: | RADIUS, TACACS+, MS-CHAP, Secure Shell v.2 (SSH2) |
|---|---|
| Capacity: | Virtual interfaces (VLANs): 4096 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ Rapid Spanning Tree Protocol instances: 512 ¦ ACL entries: 4096 ¦ IPv4 routes (Unicast): 24000 ¦ IPv4 hosts: 64000 ¦ IPv4 routes (Multicast): 8000 ¦ OSPF routes: 256 |
| Compliant Standards: | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, GB 4943, Directive 2004/108/EC, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IE, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3ba, IEEE 802.1AX, IEEE 1588-2008 |
| Depth: | 46.7 cm |
| Device Type: | Switch - 24 ports - L3 - Managed |
| Enclosure Type: | Rack-mountable 1U |
| Encryption Algorithm: | MD5, AES |
| Features: | Flow control, NAT support, BOOTP support, ARP support, trunking, VLAN support, Syslog support, Broadcast Storm Control, Multicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Tran |
| Flash Memory: | 2 GB |
| Height: | 4.36 cm |
| Humidity Range Operating: | 10 - 85% (non-condensing) |
| Humidity Range Storage: | 5 - 95% (non-condensing) |
| Installed Qty: | 2 |
| Interfaces: | 1 x serial (console) RJ-45 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 24 x SFP+ ¦ 2 x USB Type A ¦ 24 x SFP+ Ports on Demand |
| Jumbo Frame Support: | 9216 bytes |
| MAC Address Table Size: | 64K entries |
| MTBF: | 317,030 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Max Supported Qty: | 2 |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Performance: | Switching capacity: 960 Gbps ¦ Forwarding performance: 720 Mpps |
| Ports: | 24 x SFP+ Ports on Demand + 24 x SFP+ |
| Power Device: | Internal power supply - hot-plug |
| Power Provided: | 400 Watt |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Remote Management Protocol: | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2, CLI |
| Routing Protocol: | OSPF, RIP-2, HSRP, VRRP, OSPFv2, static IP routing, ECMP, CIDR |
| Software Included: | Cisco NX-OS |
| Subtype: | 10 Gigabit Ethernet |
| Version: | original |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Weight: | 7.9 kg |
| Width: | 43.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
