Cisco IE-3100-8T2C-E
IE3100 w/8GE Copper, 2GE Combo,Fixed sys,Network Essentials.
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
IE3100 w/8GE Copper, 2GE Combo,Fixed sys,Network Essentials.
| Capacity: | Queues per port (egress): 8 ¦ Unicast MAC addresses: 8000 ¦ IGMP groups: 512 ¦ VLAN groups: 256 ¦ IPv4 unicast indirect routes: 2000 ¦ STP instances: 128 |
|---|---|
| Compliant Standards: | EN55024, ICES-003 Class A, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, EN 61131-2, IEC 60068-2-64, IEC 60068-2-14, IEC 60068-2-52, ISO 12944-6, IEC 60068-2-60, EN 50121-4, IP30, VCCI Class A, NEMA TS-2, China RoHS, RCM, EN 50121-3-2, EN 61326, IEC 6006, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 1588v2, IEEE 1613 |
| Depth: | 7.62 cm |
| Device Type: | Switch - 10 ports |
| Enclosure Type: | DIN rail mountable |
| Features: | Layer 2 switching, REP, MRP |
| Height: | 11 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Interfaces: | 8 x 10/100/1000 Base-T RJ-45 ¦ 2 x 1000Base-TX ¦ 1 x console RJ-45 ¦ 1 x micro-USB mini-USB |
| MTBF: | 854,560 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 75 °C |
| Max Storage Temperature: | 85 °C |
| Min Operating Temperature: | -40 °C |
| Min Storage Temperature: | -40 °C |
| Ports: | 8 x 10/100/1000 + 2 x combo Gigabit |
| Power Device: | External power adapter |
| Power Provided: | 12 - 48 V - 2 A |
| RAM: | 4 GB |
| Remote Management Protocol: | SNMP, NETCONF, RESTCONF, Modbus, DHCP |
| Version: | original |
| Weight: | 860 g |
| Width: | 12.7 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switches International.pdf |
