Cisco NCS-57B1-6D24-SYS
NCS57B1 Fixed Base HW Flexible Consumption Need Smart Lic
Product images and accessories are provided by a content provider. Images may differ slightly from the original and are for illustrative purposes. Compatibility guarantee for accessories can not be guaranteed. The scope of delivery corresponds to the item description (if necessary identical item) Please note the product and condition description.
NCS57B1 Fixed Base HW Flexible Consumption Need Smart Lic
| Authentication Method: | TACACS+, Secure Shell (SSH) |
|---|---|
| Capacity: | QoS queues: 8 |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.1ad, IEEE 802.3ad (LACP), Directive 2004/108/EC, Directive 2006/95/EC, UL 60950-1 Second Edition, CAN/CSA C22.2 No. 60950-1 Third Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, EN 62368-1 Third Edition, IEC 62368-1 T |
| Connectivity Technology: | Wired |
| Data Link Protocol: | 10 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 400 Gigabit Ethernet |
| Depth: | 60 cm |
| Device Type: | Router |
| Enclosure Type: | Front to back airflow rack-mountable - 1U |
| Features: | MACsec, SyncE, PTP, hot swappable 5+1 fans, VLAN encapsulation, LACP support, ACL support, EFP, VLAN trunking, L3VPN support, LDP, EoMPLS, TI-LFA, SR-TE, QoS, DSCP support, ZTP, iPXE, AAA, RPL support, MIB |
| Hard Drive: | 128 GB |
| Height: | 4.3 cm |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Installed Qty: | 2 (max) |
| Interfaces: | 6 x 400Gb Ethernet - QSFP-DD ¦ 24 x 100Gb Ethernet - QSFP-DD ¦ Management: 1 x RJ-45 ¦ Console: 1 x RJ-45 ¦ USB: 1 x |
| Jumbo Frame Support: | 9216 bytes |
| MTBF: | 134,790 hours |
| Manufacturer: | Cisco Meraki |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 0 °C |
| Network / Transport Protocol: | IPv4, IPv6 |
| Performance: | Throughput: 4.8 Tbps ¦ Route scale: up to 2.7M FIB entries |
| Power Consumption Operational: | 500 watt |
| Power Device: | Internal power supply - hot-plug |
| Power Redundancy: | Optional |
| Pricing Type: | Flexible Consumption Model |
| RAM: | 32 GB |
| Remote Management Protocol: | NETCONF, YANG, TACACS+, SSH, SNMP 3, XML, JSON, GPB, SNMP, OAM |
| Routing Protocol: | ECMP, VRRP, static IP routing, OSPFv2, OSPFv3, IS-ISv4, IS-ISv6, BGP, Bidirectional Forwarding Detection (BFD), MPLS |
| Status Indicators: | Status |
| Version: | original |
| Weight: | 13.18 kg |
| Width: | 43.9 cm |
| GPSR - economic actor: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
|---|---|
| GPSR - product manufacturer: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| GPSR - EU responsible person: | Cisco Systems GmbH, Deutschland, Parkring 20, Garching, 85748, info-center@cisco.com |
| EU Data-Act-Url: | https://www.cisco.com/site/de/de/about/sitemap.html |
| Warnings: | Warnings Switches International.pdf |
| Safety instructions: | Safety instructions Switch Modules International.pdf |
